Ordering number : EN4696B

Monolithic Digital IC

LB1823M

Power Brushless Motor Predriver IC

for OA Applications

Overview

The LB1823M is a predriver IC developed for driving

power brushless motors in office automation applications.

A motor driver circuit with the desired output power

(current and voltage) can be constructed by attaching

either a driver array or discrete components at the output.

The LB1823M output supports direct PWM drive and thus

allows the implementation of low-loss drive circuits.

Additionally, the LB1823M includes several associated

circuits, such as a speed control circuit, and FG amplifier,

and an integrating amplifier, on chip.

Package Dimensions

unit: mm

3073A-MFP30SD

[LB1823M]

Features

鈥?/div>

Direct PWM drive output

Crystal oscillator circuit

Speed discriminator plus PLL speed control system

Lock detector output

Forward/reverse switching circuit

Braking circuit (short braking technique)

Start/stop switching circuit

Over current limiter circuit (OCL)

Thermal shutdown circuit (TSD)

Built-in FG amplifier, integrating amplifier

Shunt regulator output (7.0 V)

鈭廠ANYO:

MFP30SD

SANYO Electric Co.,Ltd. Semiconductor Bussiness Headquarters

TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110 JAPAN

13097HA(OT)/83095HA (OT) No. 4696-1/11
