LAN83C171 Datasheet

  • LAN83C171

  • EPIC/XF ACPI/PC 97 Compliant Integrated PCI 10/100 Mbps Fast...

  • 90頁

  • SMSC   SMSC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

LAN83C171
ADVANCE INFORMATION
LAN83C171 - EPIC/XF
ACPI/PC 97 Compliant Integrated PCI 10/100
Mbps Fast Ethernet Controller
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
IEEE 802.3 Compatible 10/100 Mbps Fast
Ethernet Controller
Fully Compliant Glueless PCI Version 2.1
Bus Interface
Support Included for CardBus Status
Registers
PCI Universal 3V/5V Output Drives
Preemptive Interrupt Support for Efficient
Network Packet Processing
High Performance Two Channel Bus Master
(132 Mbps)
Scatter/Gather DMA Capability
Programmable Burst Length Counter
ACPI Compliant for
-
PCI Bus Class Specification
-
Network Device Class Specification
PC 97 Compliant
Wake-Up on Magic Packet
TM
Detection
and/or Network Link-Down Occurrence
Special Low Power State Mode For
Scanning Magic Packets
TM
Upon PCI Bus
Power Loss
Supports Chaining of Transmit Packets
Optional Early Transmit and Early Receive
Optional Receive Lookahead Buffering
Mode
Automatic Rejection of Runt Packets
Automatic Retransmission of Collision
Frames from Internal Buffer
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Automatic Padding of Short Frames
4.5 Kbyte On-Chip Receive Buffer and 1.5
Kbyte On-Chip Transmit Buffer Eliminate
Bus Latency Issues
Optional Variable Depth, 32 Bit Wide
External Receive Buffer (0, 16, 32 or 128
Kbytes)
Big or Little Endian Byte Ordering
Capable of Supporting 64 Kbyte Expansion
Boot Flash RAM
IEEE Standard MII Interface to Physical
Layer
Interface to LAN83C694 - Shares MII Pins
Serial MII Management Interface
Serial EEPROM Interface for Storage of
LAN Address and Configuration Information
On-Chip Clock Multiplier
Low Power Sleep Mode
Support for Full Duplex Ethernet
Internal and External Loopback Diagnostic
Functions
Simple I/O Pin Mapping Scheme to
Facilitate In-Circuit Test
Single 5V Power Supply
208 Pin QFP Package
Software Drivers to Operate with Major
Operating Systems, Including:
-
NDIS 3.4 and 5 for Microsoft
-
DOS ODI for Novell
