LA70QS Semiconductor Fuses
700 VAC
I
Very Fast-Acting
I
35 鈥?800 Amperes
SPECIFICATIONS
Voltage Rating:
AC: 700 Volts
DC: 700 Volts
Interrupting Rating:
AC: 200,000 Amperes
DC: 100,000 Amperes
Ampere Range:
35 鈥?800 Amperes
Approvals:
UL Recognized under the components
program.
CSA Certified.
NEW
ORDERING INFORMATION
LA 70 QS 150 -4
Voltage
(700)
Ampere Rating
Mounting Type
Littelfuse
Style
(Blades/Bolt-in)
Littelfuse鈥檚 LA70QS semiconductor fuses were developed to
provide improved performance required by today鈥檚 new
equipment. The LA70QS features lower I
2
t, improved cycling,
and lower watts loss. It is the best choice for the protection of
dynamic solid-state equipment.
FEATURES
I
I
I
I
I
Very low I
2
t
improved protection of equipment.
Superior cycling ability
for long, reliable life on high
cycling loading.
Lower watts loss
for cooler operation.
700 Volt AC/DC rating
provides greater design versatility.
Compact sizes
allow down-sizing of equipment.
APPLICATIONS
Protection of 700 volt or less solid state equipment such as
motor drives, UPS, inverters, etc.
94
