Ordering number : ENN6518
Monolithic Linear IC
LA6538T
Single-Phase Full-Wave Fan Motor Driver
Overview
The LA6538T is optimal for use as a fan motor driver in
equipment, such as notebook personal computers and
electronic game units, that requires miniaturization and
low noise levels. This device achieves highly efficient
single-phase bipolar fan motor drive by providing a low
saturation voltage BTL output.
鈥?Ultraminiature package
(MSOP-8: 3.0
脳
4.9
脳
0.93 mm
3
)
鈥?Allows the circuit board to be miniaturized and a
large heat sink to be used.
Reference materials:
T package (MSOP-8) series fan motor drivers
LB1964T: 3 and 5 V operation, low saturation voltage
switching single-phase bipolar drive, FG output
LB11963T: 5 and 12 V operation, switching single-
phase bipolar drive, restart circuit, lock detection, 1/2
FG output
LB11964T: 5 and 12 V operation, switching single-
phase bipolar drive, restart circuit, lock detection, FG
output
Functions and Features
鈥?BTL output single-phase full-wave linear drive (gain
resistance: 180 to 500 k鈩? 360脳)
鈥?Since this device generates no switching noise, it is
optimal for fan drive in audio equipment, electronic
games, and notebook personal computers.
鈥?Supports low-voltage operation and features a wide
usable voltage range (V
CC
= 2.5 to 9.5 V).
鈥?Low saturation voltage output (Upper side + lower side
saturation voltage: V
O
sat(total) = 0.2 V (typ),
I
O
= 100 mA)
鈥?This device achieves a high coil efficiency for low
current drain, and generates minimal heat in the IC
itself.
鈥?Constant-voltage Hall bias output.
鈥?The Hall element is regulated at 2.1 V, and the
device provides a stable Hall output with excellent
temperature characteristics.
鈥?FG output
鈥?The LA6538T provides a speed detection output (an
open-collector output).
鈥?Built-in thermal protection circuit
鈥?This circuit limits the drive current to prevent
damage to or destruction of the IC when the IC chip
temperature exceeds 180擄C due to excessive output
current caused by load shorting or other problem.
Package Dimensions
unit: mm
3245-MSOP8
[LA6538T]
3.0
8
5
0.5
0.65
(0.5)
1
4
0.25
(0.85)
1.1max
0.25
0.08
3.0
4.9
SANYO: MSOP8
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft鈥檚
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
83000RM (OT) No. 6518-1/6
