Ordering number: EN7258
Monolithic Linear IC
LA5636M
DC/DC Converter Secondary Side Control IC
Overview
The LA5636M is a DC/DC Converter Secondary Side
Control IC that draws power from a car battery and is ideal
for use in rechargers for lithium ion batteries, etc. Because
this IC incorporates only the basic functions (constant
voltage control and constant current control) that are
needed in an IC for charging, it can be easily used in
combination with other ICs for charging.
Package Dimensions
unit: mm
3086B
[3086B]
10
6
0.63
1.7max
4.4
0.15
(0.5)
5.0
鈥?Includes integrated circuitry for preventing the
malfunction of the system in the event that the input
voltage (car battery voltage) drops.
鈥?Produces constant voltage output in proportion to the
PWM input signal. (Permits output voltage control by
microcontroller.)
鈥?High-precision reference current (current control amp):
92.5
碌A(chǔ)鹵2.7%
鈥?Output voltage can be set through an external resistor.
鈥?Each loop of the voltage amp and current amp is
independent.
1
5
0.35
1.0
0.1 (1.5)
SANYO: MFP-10S(225mil)
Specifications
Maximum Ratings
at Ta = 25擄C
Parameter
Supply voltage
Allowable power dissipation
DOUT terminal current/voltage
PWM input voltage
ICONST terminal voltage
C1 terminal voltage
Operating temperature
Performance garanteed temperature
Storage temperature
Symbol
V
CC
max
Pd max
Idtmax/Vdtmax
V
pwm
VICONST
VC1
Topr1
Topr2
Tstg
Conditions
Ratings
14.5
350
1/ 鈥?.2 to V
CC
鈥?.2 to 3.0
鈥?.2 to V
CC
鈥?.2 to V
CC
鈥?0 to +85
鈥?5 to +75
鈥?0 to +150
Unit
V
mW
mA/V
V
V
V
擄C
擄C
擄C
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft鈥檚
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
52303AS (II) No.7258-1/7
6.4
Features
1
2
3
4
5
6
7
