LA3376 Datasheet

  • LA3376

  • Pilot Cancel-Provided PLL FM MPX Demodulator for Car Stereos

  • 12頁

  • SANYO

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Ordering number:ENN1236C
Monolithic Digital IC
LA3376
Pilot Cancel-Provided PLL
FM MPX Demodulator for Car Stereos
Overview
The LA3376 is a multiplex IC for use in car stereo applica-
tions. It contains 2 functions of skip noise control and pilot
cancel and is packaged in 16-pin SEP
Package Dimensions
unit:mm
3193-SIP16Z
[LA3376]
24.2
3.25
Functions
鈥?Pilot canceler (level-follow-up type).
鈥?Stereo noise controller (SNC function).
鈥?High-cut controller (HCC function).
鈥?Automatic selection between stereo and monaural.
鈥?VCO oacillation stop
鈥?Forced monaural function (stereo lamp off, pilot cancel
and HCC function hold) of reception mode is realized
by disconnecting pin 10 from V
CC
.
8.8max
3.6
6.5
1
0.85
3.0
3.0
0.5
16
0.25
1.5
1.5
SANYO : SIP16Z
Method of forced monaural at stereo reception
PIN 8 GND
7.3V or more applied to PIN 7
PIN 11 GND
PIN 10 disconnected
LA3375
LA3376
Lamp
ON
OFF
OFF
OFF
HCC
Pilot cancel
擄
擄
擄
脳
擄
擄
擄
擄
擄
脳
擄
擄
擄
脳
脳
擄
Features
鈥?Low distortion (0.05% typ 300mV input mono).
鈥?Good ripple rejection of power supply (35dB typ.).
鈥?Wide supply voltage range (V
CC
=6.5 to 14V).
鈥?Good space factor due to single-end package.
鈥?Easy to draw printed circuit pattern due to pin-to-pin space
of 3mm.
Any and all SANYO products described or contained herein do not have specifications that can handle
applications that require extremely high levels of reliability, such as life-support systems, aircraft鈥檚
control systems, or other applications whose failure can be reasonably expected to result in serious
physical and/or material damage. Consult with your SANYO representative nearest you before using
any SANYO products described or contained herein in such applications.
SANYO assumes no responsibility for equipment failures that result from using products at values that
exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges,or other
parameters) listed in products specifications of any and all SANYO products described or contained
herein.
SANYO Electric Co.,Ltd. Semiconductor Company
TOKYO OFFICE Tokyo Bldg., 1-10, 1 Chome, Ueno, Taito-ku, TOKYO, 110-8534 JAPAN
10700TH (KT)/90196RM/D177KI/8044KI/5205KI/ No.1236鈥?/12
2.2min
