L9824

OCTAL PARALLEL LOW SIDE DRIVER

.

.

.

.

.

.

.

.

.

.

ADVANCE DAT A

OPERATING DC SUPPLY VOLTAGE RANGE

5V TO 25V

SUPPLY OVERVOLTAGE PULSE UP TO 40V

VERY LOW STANDBY QUIESCENT CUR-

RENT 100碌A(chǔ)

EIGHT BIT PARALLEL STRUCTURE WITH ME-

MORY FEATURE

BIDIRECTIONAL INPUTS-OUTPUTS

碌C

COMPATIBLEINPUT LEVELS WITH THRE-

SHOLD HYSTERESIS

INTERNAL 4.5V REFERENCE DEFINING THE

OUTPUT HIGH LEVELS

EIGHT HIGH CURRENT OUTPUTS FOR DC

CURRENTS UP TO 350mA WITH ON RESI-

STANCE LESS THAN 3鈩?(typ. 1,5鈩?

OUTPUT SHORT CIRCUIT PROTECTION

WITH TIME DELAY CHARACTERISTICS FOR

DRIVING LAMPS

THERMAL OVERLOAD PROTECTION

MULTIPOWER BCD TECHNOLOGY

DIP20

SO20

ORDERING NUMBERS

: L9824 (DIP20)

L9824D (SO20)

DESCRIPTION

The L9824 is an octal parallel input power interface

circuit in the Multipower BCD technology with bidi-

rectional inputs and outputs and the output status

monitoring.

BLOCK DIAGRAM

February 1995

1/11

This is advanced information on a new product now in development or undergoing evaluation. Details are subject to change without notice.
