L80225 10/100 MbpsTX/10BT
Ethernet Physical Layer Device
(PHY)
Technical Manual
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Single Chip 100Base-TX /10Base-T
physical layer solution
Dual Speed - 10/100 Mbps
Half and Full Duplex
MII interface to Ethernet Controller
MI interface for con鏗乬uration & status
Optional Repeater Interface
AutoNegotiation: 10/100, Full/Half
Duplex
Meets all applicable IEEE 802.3
standards
Advertisement control through pins
Adaptive Equalizer
鈥?/div>
鈥?/div>
鈥?/div>
On-chip wave shaping - no external 鏗乴ters
required
Baseline Wander Correction
LED outputs
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Link
Activity
Collision
Full Duplex
10/100
鈥?/div>
鈥?/div>
鈥?/div>
Few external components
3.3 V supply with 5 V tolerant I/O
44 PLCC
Contents
Description
- - - - - - - - - - - - - - - - - - - - - 2
Pin Description
- - - - - - - - - - - - - - - - - - 4
Block Diagram
- - - - - - - - - - - - - - - - - - - 8
Functional Description
- - - - - - - - - - - - - 9
Register Description-
- - - - - - - - - - - - - -43
Note:
Application Information
- - - - - - - - - - - - 51
Speci鏗乧ations
- - - - - - - - - - - - - - - - - - - 65
Ordering Information
- - - - - - - - - - - - - - 84
Revision History
- - - - - - - - - - - - - - - - - 84
Surface Mount Packages
- - - - - - - - - - - 87
Check for the latest revision of this document before start-
ing any designs. This document is available on the Web, at
www.lsilogic.com
1 of 88
MD400182/B
April, 2002
Copyright 漏 1999-2002 by LSI Logic Corporation. All rights reserved.
