L7055-04 Datasheet

  • L7055-04

  • HIGH-POWER INFRARED PULSED LASER DIODE

  • 2頁

  • HAMAMATSU

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

HIGH-POWER
INFRARED PULSED LASER DIODE
L7055-04
鈻燜EATURES
鈼廐igh
output power (蠁ep鈮?0W)
鈼廐igh
speed rise time (tr=0.5 ns typ.)
鈻燗PPLICATIONS
鈼廘aser
rader
鈼廟ange
finder
鈼廍xcitation
light source
鈼廜ptical
trigger
鈼廠ecurity
barrier
Figure 1: Dimensional Outline (Unit: mm)
Glass Window
LD Chip
9.0
-0.1
鈥冣€?/div>
5.7
鹵
0.2
2.8
鹵
0.3
5.1
鹵
0.5
7.0
鹵
0.5
(Pin Connection)
+0
鈻燗BSOLUTE
MAXIMUM RATINGS
Parameter
Pulsed Foward Current
Reverse Voltage
Pulsed Radiant Output Power
Pulse Duration (FWHM)
Duty Ratio
Operating Temperature
Storage Temperature
Symbol
I
FP
V
R
蠁
ep
t
w
DR
T
op
T
stg
Value
30
2
40
100
0.075
-30 to +85
-40 to +125
Unit
A
V
W
ns
%
鈩?/div>
鈩?/div>
Anode
Cathode
Bottom View
NC (Case)
0.45
2.54
Side View
1.0
0.4
1.5
2.4
Anode
Cathode
鈻燛LECTRICAL
AND OPTICAL CHARACTERISTICS (Ta=25鈩?
Parameter
Pulsed Radiant Power
Peak Emission Wavelength
Spectral Radiation Half Bandwidth
Forward Voltage
Rise Time
Beam Spread Angle : Parallel
: Vertical
Lasing Threshold Current
Symbol
蠁
ep
位p
螖位
V
F
tr
胃//
胃鈯?/div>
Ith
FWHM
I
FP
=20A
I
FP
=20A
Condition
I
FP
=20A
Min.
20
-
-
-
-
6
29
-
Typ.
-
870
4
6
0.5
8
32
1
Max.
-
-
-
-
-
10
35
-
Unit
W
nm
nm
V
ns
degree
degree
A
Note: General operating condition蠁
ep
鈮?0
W, tw鈮?0 ns, Repetition frequency鈮? kHz
Information furnished by HAMAMATSU is believed to be reliable. However, no responsibility is assumed for possible inaccuracies or omissions.
C
Specifications are subject to change without notice. No patent rights are granted to any of the circuits described herein.
鈼?/div>
1998 Hamamatsu Photonics K.K.
