L6571A

L6571B

HIGH VOLTAGE HALF BRIDGE

DRIVER WITH OSCILLATOR

s

s

s

s

HIGH VOLTAGE RAIL UP TO 600V

BCD OFF LINE TECHNOLOGY

15.6V ZENER CLAMP ON V

S

DRIVER CURRENT CAPABILITY:

- SINK CURRENT = 270mA

- SOURCE CURRENT = 170mA

VERY LOW START UP CURRENT: 150碌A

UNDER VOLTAGE LOCKOUT WITH

HYSTERESIS

PROGRAMMABLE OSCILLATOR

FREQUENCY

DEAD TIME 1.25碌s (L6571A) or 0.72碌s

(L6571B)

dV/dt IMMUNITY UP TO 鹵50V/ns

ESD PROTECTION

s

s

s

s

s

s

Minidip

SO8

ORDERING NUMBERS:

L6571A

L6571AD

L6571B

L6571BD

tor. The internal circuitry of the device allows it to be

driven also by external logic signal.

The output drivers are designed to drive external n-

channel power MOSFET and IGBT. The internal log-

ic assures a dead time to avoid cross-conduction of

the power devices.

Two version are available: L6571A and L6571B.

They differ in the internal dead time: 1.25碌s and

0.72碌s (typ.)

DESCRIPTION

The device is a high voltage half bridge driver with

built in oscillator. The frequency of the oscillator can

be programmed using external resistor and capaci-

BLOCK DIAGRAM

H.V.

C

VS

V

S

1

R

HV

BOOT

8

BIAS

REGULATOR

LEVEL

SHIFTER

7

HIGH

SIDE

DRIVER

HVG

C

BOOT

V

S

R

F

R

F

C

F

COMP

2

BUFFER

6

OUT

LOAD

C

F

3

COMP

V

S

LOGIC

LOW SIDE

DRIVER

5

D96IN433

LVG

GND

4

September 2000

1/8
