L64388 Datasheet

  • L64388

  • L64388 Remote Access Processor (RAP) Chip data sheet/5/98

  • 131.23KB

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

L64388
Remote Access Processor
(RAP鈩? Chip
Datasheet
The L64388 Remote Access Processor (RAP鈩? chip is a general-
purpose, high-performance communications processor for remote access
applications, including high-speed Ethernet LAN-to-WAN
internetworking. Based on LSI Logic鈥檚 CoreWare
廬
methodology, the
RAP chip integrates a MIPS RISC processor, DMA controller, Ethernet
controller, and serial wide area network controllers (SWCs) on a single
chip. The RAP chip also includes a peripheral component interconnect
(PCI) interface for connecting to a 33-MHz, 32-bit PCI bus. It contains a
modem interface with integrated voice and data ports.
Figure 1 illustrates the RAP chip in a general internetworking application.
Local data traf鏗乧 on the 10/100-Mbit Ethernet LAN or server data traf鏗乧
on the PCI bus is internetworked with various WAN technologies,
including POTS (plain old telephone system), ISDN (integrated services
digital network), or high-speed digital WAN, such as ADSL (asymmetric
digital subscriber line), DS-1/E-1, DS-3, or HFC (hybrid 鏗乥er coaxial).
Figure 1 RAP Internetworking Application
10/100-Mbit Ethernet
Workstation
Ethernet
Port
Remote Access
Processor
ISDN
Basic Rate Interface (BRI) Small Of鏗乧e/
Home Of鏗乧e
High Speed Digital
(SOHO)
ISDN
WAN
V.34
V.34 Analog
Analog
High Speed
Digital
Portable
Workstation
PCI
Server
Network Server
Server
May 1998
Copyright 漏 1995鈥?998 by LSI Logic Corporation. All rights reserved.
1
