KK74HC164AD Datasheet

  • KK74HC164AD

  • 8-Bit Serial-Input/Parallel-Output Shift Register High-Perfo...

  • 6頁

  • KODENSHI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TECHNICAL DATA
KK74HC164袗
8-Bit Serial-Input/Parallel-Output
Shift Register
High-Performance Silicon-Gate CMOS
The
KK74HC164A
is identical in pinout to the LS/ALS164. The
device inputs are compatible with standard CMOS outputs; with pullup
resistors, they are compatible with LS/ALSTTL outputs.
The
KK74HC164A
is an 8-bit, serial-input to parallel-output shift
register. Two serial data inputs, A1 and A2, are provided so that one input
may be used as a data enable. Data is entered on each rising edge of the
clock. The active-low asynchronous Reset overrides theClock and Serial
Data inputs.
鈥?/div>
Outputs Directly Interface to CMOS, NMOS, and TTL
鈥?/div>
Operating Voltage Range: 2.0 to 6.0 V
鈥?/div>
Low Input Current: 1.0
碌A
鈥?/div>
High Noise Immunity Characteristic of CMOS Devices
ORDERING INFORMATION
KK74HC164袗N
Plastic
KK74HC164袗D
SOIC
T
A
= -55擄 to 125擄 C for all packages
PIN ASSIGNMENT
LOGIC DIAGRAM
FUNCTION TABLE
Inputs
RESET
L
H
PIN 14 =V
CC
PIN 7 = GND
H
H
CLOCK
X
A1 A2
X X
X X
H D
D H
L
Outputs
QA QB鈥H
L鈥?L
no change
D
QAn鈥Gn
D
QAn鈥Gn
D = data input
X = don鈥檛 care
Q
An
- Q
Gn
= data shifted from the previous stage on a
rising edge at the clock input.
1
