KFF6675A
1900 MHz PCS Duplexer
Features
鈥?3.6 mm Board Height
鈥?Low Loss
鈥?Excellent Tx Isolation
Description
Surface mount, silver (Ag) coated ceramic
duplexer. Developed for use in PCS
infrastructure and subscriber applications.
Weight:
2.7 grams typical
Material: Filter is composed of a ceramic
block plated with Ag and a shield made of
nickel silver plated steel.
Filter complies with RoHS standards.
Electrical Specifications
Note: Supplier shall test each filter to the critical electrical specifications of the above table. Any subsequent audits may deviate from in value due to
measurement repeatability among different test systems. Such deviations shall not exceed the following limits:
Specification Allowance
Insertion Loss
0.1 dB
Return Loss
1.0 dB
Stopbands
1.0 dB
Document No. 008-0256-0
Page 1 of 2
Rev. X4VH
