KF3008-GR16A Datasheet

  • KF3008-GR16A

  • Thick film thermal printhead

  • 5頁

  • ROHM

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

KF3008-GR16A
Printheads
Thick film thermal printhead
KF3008-GR16A
KF3008-GR16A is a thick film thermal head developed for A4 size printer for use with Kiosk & ATM terminals.
!
Applications
Kiosk and ATM printers, Ticket printer, portable printer and various type of measurement mstruments printers.
.
!
Features
1) A new pin connector structure greatly reduces the size and weight.
2) Print material鈥檚 feeding stability increased thanks to the cover when printing.
3) Good printing easily attained thanks to big platen (Max.
蠁25mm)
compliance.
4) Thick film type with glazed components provides good printing quality even on rough paper.
!
External dimensions
(Units : mm)
230.5鹵0.3 (Heatsink width)
230 (Substrate width)
219.452 (Effective print width)
(7.1)
Dot #2592
CL
Max.23.6
Dot #1
Max.29
2.6鹵0.1
M
.
蠁
ax
25
.0
Max.11.5
No.15
CONNECTOR.B
No.1
No.15
CONNECTOR.A
No.1
蠁3H10
length 4 effective depth 3
5.1鹵0.2
蠁3H10
effective depth 3
15鹵0.2
5鹵0.2
110.25鹵0.2
3-M3 effective depth 3
200.5鹵0.2
110.25鹵0.2
Center of heat elements
1/4
