KF2008-GH40A Datasheet

  • KF2008-GH40A

  • Thick film thermal printhead (8dots / mm)

  • 5頁

  • ROHM

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

KF2008-GH40A
Printheads
Thick film thermal printhead
(8dots / mm)
KF2008-GH40A
The KF2008-GH40A is a standard type A4-size thick-film thermal printhead, developed mainly for facsimiles.
!
Applications
Facsimiles
Electric whiteboard
Measuring terminal printers
!
Features
1) A new pin connector structure greatly reduces the size and weight.
2) A newly developed 144-bit IC levels the strobe partition and reduces the noise level.
3) One rank resistance value of 3000鈩?/div>
鹵
3% eliminates the inconvenience of rank selection.
!
External dimensions
(Units : mm)
230.5鹵0.3 (HEATSINK WIDTH)
230 (SUBSTRATE WIDTH)
15.1鹵0.1
MAX 8.5
5.85鹵0.3
Dot #1
4.85鹵0.2
216 (EFFECTIVE PRINT WIDTH)
Dot #1728
16鹵0.2
No.9
RESIN COATING FOR PROTECTION OF PIN.
RESIN COATING FOR PROTECTION OF IC.
No.1
CONNECTOR B
No.9
CONNECTOR A
No.1
CENTER OF HEAT ELEMENTS
4.6鹵0.2
11.5鹵0.1
5鹵0.2
220.5鹵0.2
11.5鹵0.1
4-M3
2.6鹵0.1
MAX
.
蠁
14
.0
LABEL
1/4
