KF2004-GF60A Datasheet

  • KF2004-GF60A

  • Compact low voltage thick film thermal printhead (8dots / mm...

  • 5頁

  • ROHM

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

KF2004-GF60A
Printheads
Compact low voltage thick film
thermal printhead (8dots / mm)
KF2004-GF60A
KF2004-GF60A of low voltage thermal printheads have a 1.25-mm pitch connectors and reduced power supply circuit
voltage requirements. This makes them useful for a wide range of applications, including CAT, FET-POS and naturally,
handheld devices that demand printer heads which can operate with low supplied voltage.
Applications
Mobile printers
FET-POS printers
Hand-held printers
Debit printers
Features
1) Both the circuit voltage and the voltage required during printing are 3.3V ; this allows the design of complete printer
assemblies with energy-saving low power consumption.
2) KF2004-GF60A has a resistance value of 176鈩?and can take a maximum current of 8.5V for printing. This is useful in
applications where the peak voltage is restricted.
3) Because the connectors accept 1.25-mm pitch FFC (full flat cables) it is possible to reduce the size of printer
mechanism control boards.
4) 2-inch, 3-inch and 4-inch series are available.
External dimensions
(Unit : mm)
117
Max.16.5
2.1鹵0.3
Dot #832
Dot #1
(1.1)
(11.35)
104 (Effective Print Width)
Max.1.7
Exposed Conductor Side
14
.
蠁
.0
No.28
No.1
Connector
Ma
x
Insert Direction
1/4
