KF2003-GR40A Datasheet

  • KF2003-GR40A

  • Compact medium speed thick film thermal printhead (8dots /mm...

  • 5頁

  • ROHM

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

KF2003-GR40A
Printheads
Compact medium speed thick film
thermal printhead (8dots / mm)
KF2003-GR40A
The KF2003-GR40A is ideal for applications that require compact, lightweight thermal printheads, such as POS and label
printer applications. The 2-, 3-, and 4-inch sizes have a resolution of 203dpi. This series is suitable for a wide range of
applications.
!
Applications
POS printers
Label printers
Receipt printers
General purpose compact printers
!
Features
1) Both ROHM鈥檚 advanced LSI technology and proprietary partial glaze are used to realize higher printing efficiency. With
a high print speed of 100mm/s, this series is also suitable for thermal transfer printing.
2) Besides the fact that harness-type direct connectors at either end allow wring to be fitted as convenient, the thermal
printheads can be applied directly to the substrate without a heat sink. Both these features give engineers greater
freedom when designing the printer mechanism.
3) One rank resistance value of 800鈩?/div>
鹵
3% eliminates the inconvenience of rank selection.
!
External dimensions
(Units : mm)
83 (HEATSINK WIDTH)
72 (EFFECTIVE PRINT WIDTH)
DOT #576
DOT #1
Max.1.7
5.85
EPOXY RESIN COATED
16鹵0.2
15.1鹵1
2.6鹵0.1
M
No.9
CONNECTOR B
No.1
No.9
a
蠁
x.
14
.0
No.1
CONNECTOR A
2-M3 (EFFECTIVE DEPTH 4.5)
5
73
4.6
1/4
