JTDA 150A
145 Watts, 36 Volts, Pulsed
Avionics 960 - 1215 MHz
GENERAL DESCRIPTION
The JTDA-150A is a high power COMMON BASE bipolar transistor. It is
designed for pulsed systems in the frequency band 960-1215 MHz. The
transistor includes input and output prematch for broadband performance. The
device has gold thin-film metallization and diffused ballasting for proven
highest MTTF. Low thermal resistance Solder Sealed Package reduces
junction temperature, extends life.
CASE OUTLINE
55KT, STYLE 1
ABSOLUTE MAXIMUM RATINGS
Maximum Power Dissipation @ 25
o
C
2
Maximum Voltage and Current
BVces
Collector to Base Voltage
BVebo Emitter to Base Voltage
Ic
Collector Current
Maximum Temperatures
Storage Temperature
Operating Junction Temperature
350 Watts
50 Volts
3.5 Volts
15 Amps
- 65 to + 200
o
C
+ 200
o
C
ELECTRICAL CHARACTERISTICS @ 25
O
C
SYMBOL
Pout
Pin
Pg
畏
c
VSWR
BVebo
BVces
h
FE
CHARACTERISTICS
Power Out
Power Input
Power Gain
Collector Efficiency
Load Mismatch Tolerance
Emitter to Base Breakdown
Collector to Emitter Breakdown
DC - Current Gain
Thermal Resistance
TEST CONDITIONS
F = 960-1215 MHz
Vcc = 36 Volts
PW = Note 1
DF = Note 1
F = 1215 MHz
Ie = 20 mA
Ic = 60 mA
Ic = 5.0A, Vce = 5 V
MIN
145
24
8
45
3:1
3.5
55
20
0.5
Volts
Volts
o
TYP
MAX
UNITS
Watts
Watts
dB
%
胃jc
2
C/W
Note 1: JTIDS Pulse = 7 Micorseconds On / Off for 3.3 Millisec, 22 % Long term duty
2: At rated pulse conditions
Issue June 1996
