MICROCIRCUIT DATA SHEET

MJCD4001B-X REV 1A0

Original Creation Date: 10/16/95

Last Update Date: 07/30/99

Last Major Revision Date: 06/16/99

QUAD 2-INPUT NOR GATE WITH BUFFERED OUTPUTS

General Description

These quad gates are monolithic complementary MOS (CMOS) integrated circuits constructed

with N- and P-channel enhancement mode transistors. They have equal source and sink

current capabilities and conform to standard B series output drive. The devices also have

buffered outputs which improve transfer characteristics by providing very high gain.

All inputs are protected against static discharge with diodes to Vdd and Vss.

Industry Part Number

CD4001B

NS Part Numbers

JM4001BBCA

Prime Die

CD4001B

Controlling Document

38510/05252, amend. #3

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1

next
