JL137SXA Datasheet

  • JL137SXA

  • VOLT REGULATOR|ADJUSTABLE|-1.2 TO -37V|BIPOLAR|CAN|4PIN|META...

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MICROCIRCUIT DATA SHEET
MJLM137-H REV 0A0
3-TERMINAL VOLTAGE REGULATOR,
VOLTS AT 0.5A
General Description
The LM137H is an adjustable 3-terminal negative voltage regulator capable of supplying in
excess of -0.5A over an output voltage range of -1.2V to -37V. This regulator is
exceptionally easy to apply, requiring only 2 external resistors to set the output voltage
and 1 output capacitor for frequency compensation. The circuit design has been optimized
for excellent regulation and low thermal transients. Futher, the LM137H features internal
current limiting, thermal shutdown and safe-area compensation, making it virtually
blowout-proof against overloads.
The LM137H serve a wide variety of applications including local on-card regulation,
programmable-output voltage regulation or precision current regulation. The LM137H is an
ideal complement to the LM117H adjustable positive regulator.
Original Creation Date: 07/12/95
Last Update Date: 04/29/99
Last Major Revision Date: 04/21/99
-37 VOLTS < VO < -1.25
Industry Part Number
LM137
NS Part Numbers
JL137BXA
JL137SXA
Prime Die
LM137
Controlling Document
38510/11803,AMEND. 4
Processing
MIL-STD-883, Method 5004
Subgrp Description
1
2
3
4
5
6
7
8A
8B
9
10
11
Static tests at
Static tests at
Static tests at
Dynamic tests at
Dynamic tests at
Dynamic tests at
Functional tests at
Functional tests at
Functional tests at
Switching tests at
Switching tests at
Switching tests at
Temp (
o
C)
+25
+125
-55
+25
+125
-55
+25
+125
-55
+25
+125
-55
Quality Conformance Inspection
MIL-STD-883, Method 5005
1
