MICROCIRCUIT DATA SHEET

MJLM124A-X REV 2A1

Original Creation Date: 07/06/95

Last Update Date: 04/08/02

Last Major Revision Date: 03/28/02

QUAD OPERATIONAL AMPLIFER, SINGLE SUPPLY, LOW POWER

General Description

The LM124A consists of four independent, high gain, internally frequency compensated

operational amplifiers which were designed specifically to operate from a single power

supply over a wide range of voltages. Operation from split power supplies is also possible

and the low power supply current drain is independent of the magnitude of the power supply

voltage.

Application areas include transducer amplifiers, DC gain blocks and all the conventional

op amp circuits which now can be more easily implemented in single power supply systems.

For example, the LM124A can be directly operated off of the standard +5 VDC power supply

voltage which is used in digital systems and will easily provide the required interface

electronics without requiring the additional +15 VDC power supplies.

Industry Part Number

LM124A

NS Part Numbers

JL124ABCA

JL124ABDA

JL124ABZA

JL124ASCA

JL124ASDA

JL124ASZA

Prime Die

LM124A

Controlling Document

38510/11006,AMEND.2 CIR.F

REV B

Processing

MIL-STD-883, Method 5004

Subgrp Description

1

2

3

4

5

6

7

8A

8B

9

10

11

Static tests at

Static tests at

Static tests at

Dynamic tests at

Dynamic tests at

Dynamic tests at

Functional tests at

Functional tests at

Functional tests at

Switching tests at

Switching tests at

Switching tests at

Temp (

o

C)

+25

+125

-55

+25

+125

-55

+25

+125

-55

+25

+125

-55

Quality Conformance Inspection

MIL-STD-883, Method 5005

1
