Quadrature Hybrid
20 - 40 MHz
Features
q
q
q
q
q
JHS-114/JH-114/133
V2.00
SF-1
q
q
Octave Bandwidth
3擄 Maximum Phase Deviation from 90擄
Low loss: 0.5 dB Max.
Impedance: 50 Ohms Nom.
Input Power: 5 W. Max. @ 25擄C
Derated to 1 W. @ 100擄C
Typical Phase Linearity: 3擄 from Straight Line
MIL-STD-202 Screening Available
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵 0.010 (.xx = 鹵 0.25)
.xx = 鹵 0.02 (.x = 鹵 0.5)
Guaranteed Speci鏗乧ations*
Frequency Range
Insertion Loss (Less coupling)
Isolation
Amplitude Balance
VSWR
Deviation from Quadrature
(From -55擄C to +85擄C)
20 - 40 MHz
0.5 dB Max.**
20 dB Min.
0.75 dB Max.
1.2:1 Max.
3擄 Max.
FP-2
PIN 0.015 DIA
鹵0.005
(0.038
鹵0.13)
8 PLACES
1
2
3
4
0.312 MIN TYP
(7.9 MIN)
5
6
7
8
0.385
鹵
0.020
(9.8
鹵
0.5)
*All speci鏗乧ations apply with 50 Ohm source and load impedance.
**Average of coupled outputs less 3 dB.
This product contains elements protected by United States Patent
Number 3,484,724.
0.080 (2.0)
0.100 (2.5)
0.250 (6.3)
0.51
(12.9
鹵0.5)
0.350 (8.9)
0.150 MAX
(3.8 MAX)
0.060 (1.5)
Pin Con鏗乬uration
JHS-114
JH-114
JH-133
A; P1, B; P4, C; P8, D; P5
All other pins are ground.
A; P1, B; P4, C; P8, D; P5
All other pins are ground.
A; P5, B; P2, C; P11, D; P8
All other pins are ground
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵0.010 (.xx = 鹵0.25)
.xx = 鹵0.02 (.x = 鹵0.5)
WEIGHT (APPROX.): 0.09 OUNCES 2.5 GRAMS
TO-8-2
Phasing Diagram
A
A
B
C
D
B
C
D
All other pins are ground
Ordering Information
Model No.
JH-114 PIN
JH-133 PIN
JHS-114 PIN
Package
Flatpack
TO-8-2
SF-1
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .xxx = 鹵0.010 (.xx = 鹵0.25)
.xx = 鹵0.02 (.x = 鹵0.5)
M/A-COM Division of AMP Incorporated
s
North America: Tel. (800) 366-2266, Fax (800) 618-8883
s
Asia/Paci鏗乧: Tel. +85 2 2111 8088, Fax +85 2 2111 8087
s
Europe: Tel. +44 (1344) 869 595, Fax +44 (1344) 300 020
www.macom.com
AMP and Connecting at a Higher Level are trademarks.
Speci鏗乧ations subject to change without notice.
