P
ULSE
J
ACK
1XN GangjackL
Description:
TM
www.pulseeng.com
10/100 Base-TX RJ45 1XN Tab-DOWN with or without LEDs integrated magnetics connector (ICM) designed to
support applications such as: SOHO (ADSL modems), LAN-on-Motherboard (LOM), Hub and Switches.
Features and Benefits:
RJ45 1xN, Tab-DOWN 8-pin with internal magnetics
Options: 1x2, 1x4, 1x6, and 1x8 for 10/100 Base-TX
Available with and without LEDs
Suitable for CAT 5 and 6 Fast Ethernet cable or better UTP
Internal magnetics are 100% electrically tested for HI-POT
and functionality
Electrical Performance Summary:
Internal magnetics options available
Meets or exceeds IEEE 802.3ab standards for 1000Base-T
350 碌H minimum OCL with 8 mA bias current
High performance for maximum EMI suppression
Minimum 1500 Vrms isolation per IEEE 802.3 requirement
Electrical Specifications @ 25擄C 鈥?Operating Temperature 0擄C to +70擄C
Part
Number*
(Number of Ports)
TX
Turns
1,2
Ratios
RX
Tab
Option
LEDs
3
Insertion
Loss
TX/RX
(dB TYP)
1-100
MHz
Return Loss
(dB TYP)
100
鈩?(
鹵
15
鈩?
1-10
MHz
30
MHz
60-80
MHz
1-10
MHz
Crosstalk
(dB TYP)
30-60
MHz
60-100
MHz
Common Mode
Rejection
(dB TYP)
1-50
MHz
50-130
MHz
Hipot
(MIN)
@60 Hz
1 MIN
L/R
J8064D628A
(1X2)
J8064D648A
(1X4)
J8064D668A
(1X6)
J8064D688A
(1X8)
J8064E62
(1X2)
J8064E64
(1X4)
J8064E66
(1X6)
J8064E68
(1X8)
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
1CT:1CT
DOWN
DOWN
DOWN
DOWN
DOWN
DOWN
DOWN
DOWN
G/Y
G/Y
G/Y
G/Y
錚?/div>
錚?/div>
錚?/div>
錚?/div>
-1.0
-1.0
-1.0
-1.0
-1.0
-1.0
-1.0
-1.0
-20
-20
-20
-20
-20
-20
-20
-20
-16
-16
-16
-16
-16
-16
-16
-16
-12
-12
-12
-12
-12
-12
-12
-12
-40
-40
-40
-40
-40
-40
-40
-40
-35
-35
-35
-35
-35
-35
-35
-35
-30
-30
-30
-30
-30
-30
-30
-30
-30
-30
-30
-30
-30
-30
-30
-30
-20
-20
-20
-20
-20
-20
-20
-20
1500 Vrms
1500 Vrms
1500 Vrms
1500 Vrms
1500 Vrms
1500 Vrms
1500 Vrms
1500 Vrms
NOTES:
1.
Both transmit and receive channels meet IEEE 802.3 specifications.
2.
Different electrical and mechanical specifications can be accommodated.
Contact Pulse Applications Engineering.
錚?/div>
3.
LEDs Left/Right:
G
= green;
Y
= yellow; 鈥滐＇鈥?= none. Other LED options
by request.
RJ45 Durability Testing Rating
Part Number
J8 Series
Mating Force
(MAX)
5 lbs./2.268 kgs.
Unmating Force
(MAX)
5 lbs./2.268 kgs.
Durability
750 Insertions
Plug to Jack
Retention
(MIN)
20 lbs./9.072 kgs.
RJ45 Material Specification
Part
Number
J8
Series
Shield
Material
Brass
Finish
10-20碌 inches thick nickel over
10-20碌 inches thick nickel
Material
Phosphor
Bronze
Contact
Plating Area
30碌 inches gold over
30-80碌 inches nickel
Solder Area
75-300碌 inches tin-lead over
30-80碌 inches bright nickel
Material
Thermoplastic
Housing
Specification
UL 94 V-0
Notes:
1. All connector part numbers starting with the series prefix J8 comply to the above limits.
2. Connector dimensions comply with FCC dimension requirements.
US 858 674 8100
鈥?/div>
UK 44 1483 401 700
鈥?/div>
France 33 3 84 35 04 04
鈥?/div>
Singapore 65 287 8998
鈥?/div>
Taiwan 886 2 2698 0228
鈥?/div>
Hong Kong 852 2788 6588
鈥?/div>
http://www.pulseeng.com
1
PRELIMINARY J404.P (10/02)
