IZD1520U Datasheet

  • IZD1520U

  • DOT MATRIX LIQUID CRYSTAL DISPLAY CONTROLLER & DRIVER

  • 12頁

  • INTEGRAL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IZD1520U
DOT MATRIX LIQUID CRYSTAL DISPLAY CONTROLLER &
DRIVER
FEATURES
鈥?/div>
CMOS LSI chips
鈥?/div>
Connection with CPU
Can be directly coupled with 80-port or 68-port system
鈥?/div>
Available in chip form or in 100-pin plastic QFP
鈥?/div>
Pin-to-Pin Replacement for SED1520 Series
鈥?/div>
Many command set
鈥?/div>
Total 80 (segment+common) drive sets
鈥?/div>
Low power consumption - 30碌W maximum at 2kHz
external clock
鈥?/div>
Power supply V
DD
- V
SS
: 2.4 to -7.0V
V
DD
- V
5
: 3.5 to -13.0V
DESCRIPTION
The IZD1520 family of dot matrix LCD (Liquid Crystal Display) drivers are designed for the
display of characters and graphics.
The drivers generate LCD drive signals derived from bit mapped data stored in an internal
RAM.
The IZD1520 family drivers incorporate innovative circuit design strategies to achieve very
low power dissipation at a wide range of operating voltages.
These features give the designer a flexible means of implementing small to medium size
LCD displays for compact, low power systems.
The IZD1520 which is able to drive two lines of twelve characters each.
The IZD1521 which is able to drive 80 segments for extention.
ABSOLUTE MAXIMUM RATINGS
Characteristic
Supply Voltage (1)
Supply Voltage (2)
Supply Voltage (3)
Input Voltage
Output Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Soldering temperature time (10 sec
max)
Symbol
V
SS
V
5
V
1,
V
2,
V
3,
V
4
V
I
V
O
P
D
T
a
T
stg
T
sol
Value
- 8.0 ~ 0.3
- 16.5 ~ 0.3
V
5
~ 0.3
V
SS
- 0.3 ~ 0.3
V
SS
- 0.3 ~ 0.3
250
- 10 ~ + 75
- 65 ~ + 150
260
Unit
V
V
V
V
V
mW
o
o
o
C
C
C
Notes:
1.
2.
All voltages are specified relative to V
DD
= 0V.
The following relation must be always hold
V
DD
鈮?/div>
V
1
鈮?/div>
V
2
鈮?/div>
V
3
鈮?/div>
V
4
鈮
5
.
3.
Exceeding the absolute maximum ratings may cause permanent damage to
the device. Functional operating under these
conditions is not implied.
1
