IZ74LV74 Datasheet

  • IZ74LV74

  • Dual D-type flip-flop with set and reset; positive-edge trig...

  • 7頁

  • INTEGRAL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

TECHNICAL DATA
IN74LV74
Dual D-type flip-flop with set and reset;
positive-edge trigger
The IN74LV74 is a low-voltage Si-gate CMOS device and is pin and
function compatible with 74HC/HCT74.
The IN74LV74 is a dual positive edge triggered, D-type flip-flop with
individual data (D) inputs, clock (CP) inputs, set (S
D
) and (R
D
) inputs;
also complementary Q and Q outputs.
The set and reset are asynchronous active LOW inputs and operate
independently of the clock input. Information on the data input is
transferred to the Q output on the LOW-to-HIGH transition of the clock
pulse. The D inputs must be stable one set-up time prior to the LOW-to-
HIGH clock transition, for predictable operation. Schmitt-trigger action in
the clock input makes the circuit highly tolerant to slower clock rise and
fall times.
鈥?/div>
Output voltage levels are compatible with input levels of CMOS,
NMOS and TTL IC
S
鈥?/div>
Supply voltage range: 1.2 to 3.6 V
鈥?/div>
Low input current: 1.0
碌脌;
0.1
碌脌
at 脪 = 25
擄脩
鈥?/div>
High Noise Immunity Characteristic of CMOS Devices
N SUFFIX
PLASTIC
14
1
14
D SUFFIX
SOIC
1
ORDERING INFORMATION
IN74LV74N
IN74LV74D
IZ74LV74
Plastic DIP
SOIC
chip
T
A
= -40擄 to 125擄 C for all packages
PIN ASSIGNMENT
RESET 1
1
2
3
4
5
6
7
14
13
12
11
10
9
8
V CC
RESET 2
DATA2
CLOCK 2
SET 2
Q2
Q2
LOGIC DIAGRAM
DATA 1
CLOCK 1
SET 1
Q1
Q1
GND
FUNCTION TABLE
Inputs
Set
L
H
L
H
H
H
PIN 20=V
CC
PIN 10 = GND
H
H
Reset
H
L
L
H
H
H
H
H
L
H
Clock
X
X
X
Data
X
X
X
H
L
X
X
X
Outputs
Q
H
L
H*
H
L
Q
L
H
H*
L
H
No Change
No Change
No Change
*Both outputs will remain high as long as Set and
Reset are low, but the output states are unpredictable
if Set and Reset go high simultaneously.
H= high level
L = low level
X = don鈥檛 care
Z = high impedance
INTEGRAL
1
