ITC1100
1000 WATT, 50V, Pulsed
Avionics 1030 MHz
GENERAL DESCRIPTION
The
ITC1100
is a common base bipolar transistor. It is designed for pulsed
interrogator systems in the frequency band of 1030 MHz. The device has gold
thin-film metallization for proven high MTTF. The transistor includes input
returns for improved output rise time . Low thermal resistance package reduces
junction temperature which extends the life time of the product.
CASE OUTLINE
55SW, Style 1
Common Base
ABSOLUTE MAXIMUM RATINGS
Power Dissipation
Device Dissipation
1
@25擄C (P
d
)
Thermal Resistance
1
(胃
JC
)
Voltage and Current
Collector-Base Voltage
Emitter-Base Voltage
Collector Current
1
Temperatures
Storage Temperature
Operating Junction Temperature
1
3400 W
.08擄C/W
65V
3.5V
80A
-40 to +150擄C
+200擄C
ELECTRICAL CHARACTERISTICS @ 25擄C
SYMBOL
BVebo
2
BVces
BVceo
2
h
FE2
CHARACTERISTICS
Emitter-Base Breakdown(open)
Collector-Emitter Breakdown(shorted)
Collector-Emitter Breakdown (open)
DC Current Gain
TEST
CONDITIONS
Ie=50mA
Ic=30mA
Ic=30mA
Ic=5A, Vce=5V
MIN
3.5
65
30
20
TYP
MAX
UNITS
V
V
V
尾
100
FUNCTIONAL CHARACTERISTICS @ 25擄C
G
PB
畏
c
t
r
VSWR
Z
in
Z
out
1
2
Common Base Power Gain
Collector Efficiency
Rise Time
Output Load Mismatch
Series Input Impedance (Circuit
source impedance @ test cond.)
Series Output Impedance (Circuit
load impedance @ test cond.)
V
cc
= 50V, F = 1030MHz,
P
out
=1000W Peak Min, PW=1碌S, DF=1%
V
cc
= 50V, F = 1030MHz,
P
out
=1000W Peak Min, PW=1碌S, DF=1%
V
cc
= 50V, F = 1030MHz,
P
out
=1000W Peak Min, PW=1碌S, DF=1%
V
cc
= 50V, F = 1030MHz,
P
out
=1000W Peak Min, PW=1碌S, DF=1%
V
cc
= 50V, F = 1030MHz,
P
out
=1000W Peak Min, PW=1碌S, DF=1%
V
cc
= 50V, F = 1030MHz,
P
out
=1000W Peak Min, PW=1碌S, DF=1%
10
45
10.5
50
50
80
4:1
0.89 鈥?j2.3
0.54 - j2.64
dB
%
nS
唯
鈩?/div>
鈩?/div>
At rated output power and pulse conditions
Not measurable due to EB Returns
