ITAXXU1 Datasheet

  • ITAXXU1

  • TRANSIL?? ARRAY FOR DATALINE PROTECTION

  • 6頁

  • STMICROELECTRONICS   STMICROELECTRONICS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

廬
ITAxxU1
TRANSIL鈩?ARRAY
FOR DATALINE PROTECTION
ASD鈩?/div>
MAIN APPLICATIONS
Data transmission lines protection, such as :
鈻?/div>
鈻?/div>
Unipolar signal up to 5.5 V
Bipolar signal in the 鹵 2.5 V range
FEATURES
鈻?/div>
High surge capability Transil array:
I
PP
= 40 A (8/20碌s)
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
鈻?/div>
Peak pulse power : 300 W (8/20碌s)
Up to 6 bidirectional Transil functions
Low clamping factor (V
CL
/ V
BR
) at high current
level
Low leakage current
ESD protection up to 15kV
SO-8
DESCRIPTION
Transil diode arrays provide high overvoltage pro-
tection by clamping action. Their instantaneous re-
sponse to transient overvoltages makes them
particularly suited to protect voltage sensitive de-
vices such as MOS Technology and low voltage
supplied IC鈥檚.
The ITA series allies high surge capability against
energetic pulses with high voltage performance
against ESD.
Table 1: Order Codes
Part Number
ITA6V1U1
ITA6V1U1RL
Marking
6V1U1
6V1U1
Figure 1: Functional Diagram
I/O1 1
I/O2 2
I/O3 3
I/O4 4
8 I/O6
7 GND
6 GND
5 I/O5
COMPLIES WITH THE FOLLOWING STANDARDS:
鈻?/div>
IEC61000-4-2 level 4:
15kV (air discharge)
8kV (contact discharge)
MIL STD 883E-Method 3015-7: class3
25kV HBM (Human Body Model)
鈻?/div>
TM:
ASD and TRANSIL are trademarks of STMicroelectronics.
December 2004
REV. 1
1/6
