ISL9G2060EG3, ISL9G2060EP3, ISL9G2060ES3

Data Sheet

January 2001

File Number

5021

600V, SMPS II LGC Series N-Channel IGBT

[ /Title

(ISL9

G2060

EG3,

ISL9G

2060E

P3,

ISL9G

2060E

S3)

/Subjec

(600V,

SMPS

II LGC

Series

N-

Chann

IGBT)

/Autho

r ()

/Keyw

ords

(Intersi

Corpor

ation,

Semico

nducto

r 600V,

SMPS

II LGC

Series

N-

Chann

IGBT)

/Creato

The ISL9G2060EG3, ISL9G2060EP3, and ISLPG2060ES3

are a Low Gate Charge (LGC) SMPS II IGBT combine the

fast switching speed of the SMPS IGBTs along with lower

gate charge and avalanche capability (UIS). These LGC

devices shorten delay times, and reduce the power

requirement of the gate drive. These devices are ideally

suited for high voltage switched mode power supply

applications where low conduction loss, fast switching times

and UIS capability are essential. SMPS II LGC devices have

been specially designed for:

鈥?Power Factor Correction (PFC) Circuits

鈥?Full Bridge Topologies

鈥?Half Bridge Topologies

鈥?Push-Pull Circuits

鈥?Uninterruptible Power Supplies

鈥?Zero Voltage and Zero Current Switching Circuits

Formerly Developmental Type TA49438.

Features

鈥?>100kHz Operation at 390V, 20A

鈥?200kHz Operation at 390V, 9A

鈥?600V Switching SOA Capability

鈥?Typical Fall Time. . . . . . . . . . . . . . . . . .75ns at T

= 125

鈥?Low Gate Charge . . . . . . . . . . . . . . . . .37nC at V

= 15V

鈥?UIS Rated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .260mJ

鈥?Low Conduction Loss

Symbol

Ordering Information

PART NUMBER

ISL9G2060ES3

ISL9G2060EG3

ISL9G2060EP3

PACKAGE

TO-263AB

TO-247

TO-220AB

BRAND

G2060ES3

G2060EG3

G2060EP3

NOTE: When ordering, use the entire part number. Add the suf鏗亁 9A

to obtain the TO-263AB variant in tape and reel, e.g.,

ISL9G1260ES3S9A.

Packaging

JEDEC STYLE TO-247

JEDEC TO-220AB

COLLECTOR

(FLANGE)

COLLECTOR

(FLANGE)

JEDEC TO-263AB

COLLECTOR

(FLANGE)

INTERSIL CORPORATION IGBT PRODUCT IS COVERED BY ONE OR MORE OF THE FOLLOWING U.S. PATENTS

4,364,073

4,598,461

4,682,195

4,803,533

4,888,627

4,417,385

4,605,948

4,684,413

4,809,045

4,890,143

4,430,792

4,620,211

4,694,313

4,809,047

4,901,127

4,443,931

4,631,564

4,717,679

4,810,665

4,904,609

4,466,176

4,639,754

4,743,952

4,823,176

4,933,740

4,516,143

4,639,762

4,783,690

4,837,606

4,963,951

4,532,534

4,641,162

4,794,432

4,860,080

4,969,027

4,587,713

4,644,637

4,801,986

4,883,767

漏2001 Fairchild Semiconductor Corporation

ISL9G2060EG3, ISL9G2060EP3, ISL9G2060ES3 Rev. A
