TM

ISL5929

Data Sheet

February 2002

FN6021.1

Dual 14-Bit, +3.3V, 130/210+MSPS,

CommLink

TM

High Speed D/A Converter

The ISL5929 is a dual 14-bit,

130/210+MSPS (Mega Samples

Per Second), CMOS, high speed,

low power, D/A (digital to analog) converter, designed

speci鏗乧ally for use in high performance communication

systems such as base transceiver stations utilizing 2.5G or

3G cellular protocols.

This device complements the CommLink ISL5x61 and

ISL5x29 families of high speed converters, which include 8-,

10-, 12-, and 14-bit devices.

Features

鈥?Speed Grades . . . . . . . . . . . . . . . . 130M and 210+MSPS

鈥?Low Power . . . . . 233mW with 20mA Output at 130MSPS

鈥?Adjustable Full Scale Output Current . . . . . 2mA to 20mA

鈥?Guaranteed Gain Matching < 0.14dB

鈥?+3.3V Power Supply

鈥?3V LVCMOS Compatible Inputs

鈥?Excellent Spurious Free Dynamic Range

(75dBc to Nyquist, f

S

= 130MSPS, f

OUT

= 10MHz)

鈥?UMTS Adjacent Channel Power = 71dB at 19.2MHz

鈥?EDGE/GSM SFDR = 94dBc at 11MHz in 20MHz Window

鈥?Dual, 3.3V, Lower Power Replacement for AD9767

Ordering Information

PART

NUMBER

ISL5929IN

ISL5929/2IN

ISL5929EVAL1

TEMP.

RANGE

(

o

C)

-40 to 85

-40 to 85

25

PACKAGE

48 Ld LQFP

48 Ld LQFP

CLOCK

PKG. NO. SPEED

Q48.7x7A 130MHz

Q48.7x7A 210MHz

210MHz

Applications

鈥?Cellular Infrastructure - Single or Multi-Carrier: IS-136,

IS-95, GSM, EDGE, CDMA2000, WCDMA, TDS-CDMA

鈥?BWA Infrastructure

鈥?Quadrature Transmit with IF Range 0鈥?0MHz

Evaluation Platform

Pinout

ISL5929

(LQFP)

TOP VIEW

ID13(MSB)

QD0 (LSB)

QD1

鈥?Medical/Test Instrumentation and Equipment

鈥?Wireless Communication Systems

ID10

ID11

ID12

QD3

QD4

QD2

ID7

ID6

ID5

ID4

ID3

ID2

ID1

(LSB) ID0

SLEEP

D

VDD

AGND

ICOMP

1

2

3

4

5

6

7

8

9

10

11

12

48 47 46 45 44 43 42 41 40 39 38 37

36

35

34

33

32

31

30

29

28

27

26

25

13 14 15 16 17 18 19 20 21 22 23 24

ID8

QD5

ID9

QD6

QD7

QD8

QD9

QD10

QD11

QD12

QD13 (MSB)

CLK

DGND

AGND

QCOMP

REFLO

AGND

FSADJ

IOUTA

IOUTB

QOUTB

QOUTA

REFIO

NC

NC

A

VDD

1

A

VDD

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 321-724-7143

|

Intersil (and design) is a trademark of Intersil Americas Inc.

Copyright 漏 Intersil Americas Inc. 2002. All Rights Reserved

CommLink鈩?is a trademark of Intersil Americas Inc.
