IS61LV2568 Datasheet

  • IS61LV2568

  • 256K x 8 HIGH-SPEED CMOS STATIC RAM

  • 8頁

  • ISSI   ISSI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IS61LV2568
256K x 8 HIGH-SPEED CMOS STATIC RAM
FEATURES
鈥?High-speed access times:
8, 10, 12 and 15 ns
鈥?High-performance, low-power CMOS process
鈥?Multiple center power and ground pins for
greater noise immunity
鈥?Easy memory expansion with
CE
and
OE
options
鈥?/div>
CE
power-down
鈥?Low power: 540 mW @ 10 ns
36 mW standby mode
鈥?TTL compatible inputs and outputs
鈥?Single 3.3V 鹵10% power supply
鈥?Packages available:
鈥?36-pin 400-mil SOJ
鈥?44-pin TSOP (Type II)
ISSI
廬
DECEMBER 2000
DESCRIPTION
The
ISSI
IS61LV2568 is a very high-speed, low power,
262,144-word by 8-bit CMOS static RAM. The IS61LV2568
is fabricated using
ISSI
's high-performance CMOS tech-
nology. This highly reliable process coupled with innova-
tive circuit design techniques, yields higher performance
and low power consumption devices.
When
CE
is HIGH (deselected), the device assumes a
standby mode at which the power dissipation can be
reduced down to 36mW (max.) with CMOS input levels.
The IS61LV2568 operates from a single 3.3V power
supply and all inputs are TTL-compatible.
The IS61LV2568 is available in 36-pin 400-mil SOJ, and
44-pin TSOP (Type II) packages.
FUNCTIONAL BLOCK DIAGRAM
A0-A17
DECODER
256K X 8
MEMORY ARRAY
VCC
GND
I/O
DATA
CIRCUIT
I/O0-I/O7
COLUMN I/O
CE
OE
WE
CONTROL
CIRCUIT
ISSI reserves the right to make changes to its products at any time without notice in order to improve design and supply the best possible product. We assume no responsibility for any
errors which may appear in this publication. 漏 Copyright 2000, Integrated Silicon Solution, Inc.
Integrated Silicon Solution, Inc. 鈥?1-800-379-4774
Rev. A
12/19/00
1
