IS609X
IS609
MICROPROCESSOR COMPATIBLE
SCHMITT TRIGGER OPTICALLY
COUPLED ISOLATOR
APPROVALS
l
UL recognised, File No. E91231
'X' SPECIFICATION APPROVALS
l
VDE 0884 in 2 available lead forms : -
- STD
-
G form
DESCRIPTION
The IS609 is an optically coupled isolator
consisting of a Gallium Arsenide infrared emitting
diode and a Microprocessor Compatible Schmitt
trigger output mounted in a standard 6 pin dual in
line package.
FEATURES
l
Options :-
10mm lead spread - add G after part no.
Surface mount - add SM after part no.
Tape&reel - add SMT&R after part no.
l
High data rate, 1MHz typical (NRZ)
l
Microprocessor compatible drive
l
Logic compatible output sinks 16
milliamperes at 0.4 volts maximum
l
High Isolation Voltage (5.3kV
RMS
,7.5kV
PK
)
l
High common mode rejection ratio
l
Fast swiching : t
rise,
t
fall
= 100ns typical
l
Wide supply voltage capability, compatible
with all popular logic systems
l
Guaranteed On / Off threshold hysteresis
APPLICATIONS
l
Logic to logic isolator
l
Line receiver-eliminates noise and
transient problems
l
Programmable current level sensor
l
AC to TTL conversion - square wave shaping
l
Digital programming of power supplies
l
Interfaces computers with peripherals
OPTION SM
SURFACE MOUNT
OPTION G
2.54
1
7.0
6.0
7.62
max.
2
3
Dimensions in mm
6 V
CC
5
GROUND
4 V
O
8.3 max.
0.5
min.
0.48
5.1
max.
3.9
3.1
0.25
15擄
Max
ABSOLUTE MAXIMUM RATINGS
(25擄C unless otherwise specified)
Storage Temperature
-55擄C to + 150擄C
Operating Temperature
-55擄C to + 100擄C
Lead Soldering Temperature
(1/16 inch (1.6mm) from case for 10 secs) 260擄C
INPUT DIODE
Forward Current
Reverse Voltage
Power Dissipation
(derate linearly 1.33mW / 擄C above 25擄C)
60mA
6V
105mW
OUTPUT DETECTOR
V
45
allowed range
V
65
allowed range
I
4
output current
Power Dissipation
(derate linearly 2mW / 擄C above 25擄C)
0 to 16V
0 to 16V
50mA
150mW
8.3 max
POWER DISSIPATION
1.2
0.6
10.2
9.5
1.4
0.9
0.26
10.16
Total Power Dissipation
(derate linearly 2.27mW/
擄C
above 25擄C)
170mW
