Power Module for 3 hp Motor Drives
路 3 hp (2.2 kW) power output
Industrial rating at 120% overload for 1 minute
路
路
路
路
路
路
路
路
路
路
180-240V AC single-phase input, 50/60 Hz
Single-phase rectifier bridge
3-phase, short circuit rated, ultrafast IGBT inverter
HEXFRED ultrafast soft recovery freewheeling diodes
Brake IGBT and diode
Low inductance (current sense) shunts in positive
and negative DC rail
NTC temperature sensor
Pin-to-baseplate isolation 2500V rms
Easy-to-mount two-screw package
Case temperature range -25擄C to 125擄C operational
Figure 1.
IRPT2060A Power Module
IRPT2060C
IRPT2060A
Power
Module
IRPT2060D
Driver-Plus
Board
PWM
variable
frequency
output
180-240V
single-phase input
feedback
(non-isolated)
PWM
generator
Figure 2.
The IRPT2060C
control system
within a motor
