PD - _____
PRELIMINARY
IRLP2505
V
DSS
= 55V
R
DS(on)
= 0.008
鈩?/div>
I
D
= 90A
HEXFET
廬
Power MOSFET
Logic-Level Gate Drive
Advanced Process Technology
Ultra Low On-Resistance
Dynamic dv/dt Rating
175擄C Operating Temperature
Fast Switching
Fully Avalanche Rated
Description
Fifth Generation HEXFETs from International Rectifier
utilize advanced processing techniques to achieve the
lowest possible on-resistance per silicon area. This benefit,
combined with the fast switching speed and ruggedized
device design that HEXFET Power MOSFETs are well
known for, provides the designer with an extremely efficient
device for use in a wide variety of applications.
The TO-247 package is preferred for commercial-industrial
applications where higher power levels preclude the use of
TO-220 devices. The TO-247 is similar but superior to the
earlier TO-218 package because of its isolated mounting
hole.
Absolute Maximum Ratings
Parameter
I
D
@ T
C
= 25擄C
I
D
@ T
C
= 100擄C
I
DM
P
D
@T
C
= 25擄C
V
GS
E
AS
I
AR
E
AR
dv/dt
T
J
T
STG
Continuous Drain Current, V
GS
@ 10V
Continuous Drain Current, V
GS
@ 10V
Pulsed Drain Current
Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Single Pulse Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Operating Junction and
Storage Temperature Range
Soldering Temperature, for 10 seconds
Mounting torque, 6-32 or M3 screw.
Max.
90
64
360
150
1.0
鹵20
500
54
15
2.9
-55 to + 175
300 (1.6mm from case)
10 lbf鈥n (1.1N鈥)
Units
A
W
W/擄C
V
mJ
A
mJ
V/ns
擄C
Thermal Resistance
Parameter
R
胃
JC
R
胃
CS
R
胃
JA
Junction-to-Case
Case-to-Sink, Flat, Greased Surface
Junction-to-Ambient
Min.
鈥撯€撯€撯€?/div>
鈥撯€撯€撯€?/div>
鈥撯€撯€撯€?/div>
Typ.
鈥撯€撯€撯€?/div>
0.24
鈥撯€撯€撯€?/div>
Max.
1.0
鈥撯€撯€撯€?/div>
40
Units
擄C/W
8/4/95
