PD 9.1375
PRELIMINARY
Logic-Level Gate Drive
Advanced Process Technology
Ultra Low On-Resistance
Dynamic dv/dt Rating
175擄C Operating Temperature
Fast Switching
Fully Avalanche Rated
Description
Fifth Generation HEXFETs from International Rectifier utilize
advanced processing techniques to achieve extremely low on-
resistance per silicon area. This benefit, combined with the fast
switching speed and ruggedized device design for which HEXFET
Power MOSFETs are well known, provides the designer with an
extremely efficient and reliable device for use in a wide variety
of applications.
The TO-220 package is universally preferred for all commercial-
industrial applications at power dissipation levels to approximately
50 watts. The low thermal resistance and low package cost of the
TO-220 contribute to its wide acceptance throughout the industry.
IRL2910
HEXFET
廬
Power MOSFET
V
DSS
= 100V
R
DS(on)
= 0.026
鈩?/div>
I
D
= 48A
Absolute Maximum Ratings
Parameter
I
D
@ T
C
= 25擄C
I
D
@ T
C
= 100擄C
I
DM
P
D
@T
C
= 25擄C
V
GS
E
AS
I
AR
E
AR
dv/dt
T
J
T
STG
Continuous Drain Current, V
GS
@ 10V
Continuous Drain Current, V
GS
@ 10V
Pulsed Drain Current
Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Single Pulse Avalanche Energy
Avalanche Current
Repetitive Avalanche Energy
Peak Diode Recovery dv/dt
Operating Junction and
Storage Temperature Range
Soldering Temperature, for 10 seconds
Mounting torque, 6-32 or M3 srew
Max.
48
34
190
150
1.0
鹵 20
520
29
15
7.4
-55 to + 175
300 (1.6mm from case )
10 lbf鈥n (1.1N鈥)
Units
A
W
W/擄C
V
mJ
A
mJ
V/ns
擄C
Thermal Resistance
Parameter
R
胃
JC
R
胃
CS
R
胃
JA
Junction-to-Case
Case-to-Sink, Flat, Greased Surface
Junction-to-Ambient
Typ.
鈥撯€撯€?/div>
0.50
鈥撯€撯€?/div>
Max.
1.0
鈥撯€撯€?/div>
62
Units
擄C/W
擄C/W
擄C/W
