IRHNA67160 Datasheet

  • IRHNA67160

  • RADIATION HARDENED POWER MOSFET SURFACE-MOUNT (SMD-2), 100V,...

  • 8頁

  • IRF

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PD - 94299A
RADIATION HARDENED
POWER MOSFET
SURFACE-MOUNT (SMD-2)
Product Summary
Part Number Radiation Level
IRHNA67160 100K Rads (Si)
IRHNA63160
300K Rads (Si)
R
DS(on)
0.01鈩?/div>
0.01鈩?/div>
I
D
56A*
56A*
IRHNA67160
100V, N-CHANNEL
TECHNOLOGY
SMD-2
International Rectifier鈥檚 R6
TM
technology provides
superior power MOSFETs for space applications.
These devices have improved immunity to Single
Event Effect (SEE) and have been characterized for
useful performance with Linear Energy Transfer
(LET) up to 90MeV/(mg/cm
2
). Their combination of
very low
RDS(on)
and faster switching times reduces
power loss and increases power density in today鈥檚
high speed switching applications such as DC-DC
converters and motor controllers. These devices
retain all of the well established advantages of
MOSFETs such as voltage control, ease of paralleling
and temperature stability of electrical parameters.
Features:
n
n
n
n
n
n
n
n
n
n
Low R
DS(on)
Fast Switching
Single Event Effect (SEE) Hardened
Low Total Gate Charge
Simple Drive Requirements
Ease of Paralleling
Hermetically Sealed
Surface Mount
Ceramic Package
Light Weight
Absolute Maximum Ratings
Parameter
ID @ VGS = 12V, TC = 25擄C Continuous Drain Current
ID @ VGS = 12V, TC = 100擄C Continuous Drain Current
IDM
Pulsed Drain Current
脌
PD @ TC = 25擄C
VGS
EAS
IAR
EAR
dv/dt
TJ
T STG
Max. Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Single Pulse Avalanche Energy
脕
Avalanche Current
脌
Repetitive Avalanche Energy
脌
Peak Diode Recovery dv/dt
脗
Operating Junction
Storage Temperature Range
Pckg. Mounting Surface Temp.
Weight
* Current is limited by package
For footnotes refer to the last page
56*
56*
224
250
2.0
鹵20
462
56
25
5.0
-55 to 150
Pre-Irradiation
Units
A
W
W/擄C
V
mJ
A
mJ
V/ns
o
C
g
300 (for 5s)
3.3 (Typical)
www.irf.com
1
01/07/05
