International Rectifier鈥檚 RAD HARD technology
HEXFETs demonstrate immunity to SEE failure. Ad-
ditionally, under
identical
pre- and post-irradiation test
conditions, International Rectifier鈥檚 RAD HARD
HEXFETs retain
identical
electrical specifications up
to 1 x 10
5
Rads (Si) total dose. No compensation in
gate drive circuitry is required. These devices are also
capable of surviving transient ionization pulses as high
as 1 x 10
12
Rads (Si)/Sec, and return to normal op-
eration within a few microseconds. Since the RAD
HARD process utilizes International Rectifier鈥檚 pat-
ented HEXFET technology, the user can expect the
highest quality and reliability in the industry.
RAD HARD HEXFET transistors also feature all of
the well-established advantages of MOSFETs, such
as voltage control, very fast switching, ease of paral-
leling and temperature stability of the electrical pa-
rameters. They are well-suited for applications such
as switching power supplies, motor controls, invert-
ers, choppers, audio amplifiers and high-energy pulse
circuits in space and weapons environments
Product Summary
Part Number
IRHNA7260
IRHNA8260
BV
DSS
200V
200V
R
DS(on)
0.070鈩?/div>
0.070鈩?/div>
I
D
43A
43A
Features:
n
n
n
n
n
n
n
n
n
n
n
n
n
Radiation Hardened up to 1 x 10
6
Rads (Si)
Single Event Burnout (SEB) Hardened
Single Event Gate Rupture (SEGR) Hardened
Gamma Dot (Flash X-Ray) Hardened
Neutron Tolerant
Identical Pre- and Post-Electrical Test Conditions
Repetitive Avalanche Rating
Dynamic dv/dt Rating
Simple Drive Requirements
Ease of Paralleling
Hermetically Sealed
Surface Mount
Light Weight
Absolute Maximum Ratings
Parameter
ID @ VGS = 12V, TC = 25擄C Continuous Drain Current
ID @ VGS = 12V, TC = 100擄C Continuous Drain Current
IDM
PD @ TC = 25擄C
VGS
EAS
IAR
EAR
dv/dt
TJ
TSTG
Pulsed Drain Current
聛
Max. Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Single Pulse Avalanche Energy
聜
Avalanche Current
聛
Repetitive Avalanche Energy
聛
Peak Diode Recovery dv/dt
聝
Operating Junction
Storage Temperature Range
Package Mounting Surface Temperature
Weight
43
27
172
300
2.4
鹵20
500
43
30
5.7
-55 to 150
Pre-Irradiation
IRHNA7260, IRHNA8260
Units
A
W
W/擄C
V
mJ
A
mJ
V/ns
o
C
300 ( for 5 Sec.)
3.3 (typical)
g
www.irf.com
1
8/25/98
