IRFZ44VSTRL Datasheet

  • IRFZ44VSTRL

  • TRANSISTOR | MOSFET | N-CHANNEL | 60V V(BR)DSS | 55A I(D) | ...

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PD - 94050A
l
l
l
l
l
l
l
Advanced Process Technology
Ultra Low On-Resistance
Dynamic dv/dt Rating
175擄C Operating Temperature
Fast Switching
Fully Avalanche Rated
Optimized for SMPS Applications
HEXFET
廬
Power MOSFET
D
IRFZ44VS
IRFZ44VL
V
DSS
= 60V
R
DS(on)
= 16.5m鈩?/div>
G
S
I
D
= 55A
Description
Advanced HEXFET
廬
Power MOSFETs from International Rectifier utilize advanced
processing techniques to achieve extremely low on-resistance per silicon area.
This benefit, combined with the fast switching speed and ruggedized device
design that HEXFET power MOSFETs are well known for, provides the designer
with an extremely efficient and reliable device for use in a wide variety of
applications.
The D
2
Pak is a surface mount power package capable of accommodating die
sizes up to HEX-4. It provides the highest power capability and the lowest possible
on-resistance in any existing surface mount package. The D
2
Pak is suitable for
high current applications because of its low internal connection resistance and
can dissipate up to 2.0W in a typical surface mount application.
D
2
Pak
IRFZ44VS
TO-262
IRFZ44VL
The through-hole version (IRFZ44VL) is available for low-profile applications.
Absolute Maximum Ratings
Parameter
I
D
@ T
C
= 25擄C
I
D
@ T
C
= 100擄C
I
DM
P
D
@T
C
= 25擄C
V
GS
E
AS
I
AR
E
AR
dv/dt
T
J
T
STG
Continuous Drain Current, V
GS
@ 10V
Continuous Drain Current, V
GS
@ 10V
Pulsed Drain Current
聛
Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Single Pulse Avalanche Energy
聜
Avalanche Current
聛
Repetitive Avalanche Energy
聛
Peak Diode Recovery dv/dt
聝
Operating Junction and
Storage Temperature Range
Soldering Temperature, for 10 seconds
Max.
55
39
220
115
0.77
鹵 20
115
55
11
4.5
-55 to + 175
300 (1.6mm from case )
Units
A
W
W/擄C
V
mJ
A
mJ
V/ns
擄C
Thermal Resistance
Parameter
R
胃JC
R
胃JA
Junction-to-Case
Junction-to-Ambient
Typ.
鈥撯€撯€?/div>
鈥撯€撯€?/div>
Max.
1.3
40
Units
擄C/W
www.irf.com
1
01/04/02

IRFZ44VSTRL 產品屬性

  • 800

  • 分離式半導體產品

  • FET - 單

  • HEXFET®

  • MOSFET N 通道，金屬氧化物

  • 標準型

  • 60V

  • 55A

  • 16.5 毫歐 @ 31A，10V

  • 4V @ 250µA

  • 67nC @ 10V

  • 1812pF @ 25V

  • 115W

  • 表面貼裝

  • TO-263-3，D²Pak（2 引線+接片），TO-263AB

  • D2PAK

  • 帶卷 (TR)
