IRFIZ48VPBF Datasheet

  • IRFIZ48VPBF

  • HEXFET Power MOSFET

  • 97.53KB

  • 8頁

  • IRF

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PD-94072
IRFIZ48V
HEXFET
廬
Power MOSFET
Advanced Process Technology
l
Ultra Low On-Resistance
l
Isolated Package
l
High Voltage Isolation = 2.5KVRMS
聢
l
Fast Switching
l
Fully Avalanche Rated
l
Optimized for SMPS Applications
Description
l
D
V
DSS
= 60V
R
DS(on)
= 12m鈩?/div>
G
S
I
D
= 39A
Advanced HEXFET
廬
Power MOSFETs from International
Rectifier utilize advanced processing techniques to achieve
extremely low on-resistance per silicon area. This benefit,
combined with the fast switching speed and ruggedized
device design that HEXFET power MOSFETs are well
known for, provides the designer with an extremely efficient
and reliable device for use in a wide variety of applications.
The TO-220 Fullpak eliminates the need for additional
insulating hardware in commercial-industrial applications.
The moulding compound used provides a high isolation
capability and a low thermal resistance between the tab and
external heatsink. This isolation is equivalent to using a 100
micron mica barrier with standard TO-220 product. The
Fullpak is mounted to a heatsink using a single clip or by a
single screw fixing.
TO-220 FULLPAK
Absolute Maximum Ratings
Parameter
I
D
@ T
C
= 25擄C
I
D
@ T
C
= 100擄C
I
DM
P
D
@T
C
= 25擄C
V
GS
I
AR
E
AR
dv/dt
T
J
T
STG
Continuous Drain Current, V
GS
@ 10V
Continuous Drain Current, V
GS
@ 10V
Pulsed Drain Current
聛聡
Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Avalanche Current
聛聡
Repetitive Avalanche Energy
聛聡
Peak Diode Recovery dv/dt
聝聡
Operating Junction and
Storage Temperature Range
Soldering Temperature, for 10 seconds
Mounting torque, 6-32 or M3 srew
Max.
39
27
290
43
0.29
鹵 20
72
15
5.3
-55 to + 175
300 (1.6mm from case )
10 lbf鈥n (1.1N鈥)
Units
A
W
W/擄C
V
A
mJ
V/ns
擄C
Thermal Resistance
Parameter
R
胃JC
R
胃JA
Junction-to-Case
Junction-to-Ambient
Typ.
鈥撯€撯€?/div>
鈥撯€撯€?/div>
Max.
3.5
65
Units
擄C/W
www.irf.com
1
02/12/01

IRFIZ48VPBF 產品屬性

  • 500

  • 分離式半導體產品

  • FET - 單

  • HEXFET®

  • MOSFET N 通道，金屬氧化物

  • 標準型

  • 60V

  • 39A

  • 12 毫歐 @ 43A，10V

  • 4V @ 250µA

  • 110nC @ 10V

  • 1985pF @ 25V

  • 43W

  • 通孔

  • TO-220-3 整包

  • TO-220AB 整包

  • 管件

  • *IRFIZ48VPBF
