Data Sheet 60051-H
(NOTE: For new designs, we
recommend IR鈥檚 new products IPS521 and IPS521S)
IR6226
INTELLIGENT HIGH SIDE MOSFET POWER SWITCH
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Current limit for short circuit protection
Over-temperature protection
Active output negative clamp
Reverse battery protection for logic circuit
Broken ground protection
Short to Vcc protection
Low noise charge pump
Sleep mode supply current
4kV ESD protection on all leads
Logic ground isolated from power ground
Product summary
V
cc(op)
5-50V
R
DS
(on)
I
lim
T
j(sd)
E
av
Applications
Truth Table
Condition
Normal
Normal
Output Open
Output Open
Shorted Output
Out
In
H
H
L
L
H
H
L
H
H
Current-Limiting
Linear Mode
100m
鈩?/div>
20A
170
o
C
200mJ
General Description
The IR6226 is a 5 terminal monolithic HIGH SIDE SWITCH with
built in short circuit, over- temperature, ESD protections, induc-
tive load turn off capability and diagnostic feedback.
The on-chip protection circuit limits the average current
during short circuit if the drain current exceeds 20A. The
protection circuit latches off the high side switch if the junction
temperature exceeds 170
o
C and latches on after the junction
temperature falls by 10
o
C. The Vcc (drain) to OUT (source)
voltage is actively clamped at 55V, improving its performance
during turn off with inductive loads.
The on-chip charge pump high side driver stage is floating and
referenced to the source of the Power MOSFET. Thus the logic
to power ground isolation can be as high as 50V. This allows
operation with larger offset as well as controlling the switch
during load energy recirculation or regeneration.
A diagnostic pin is provided for status feedback of short
circuit, over temperature and open load detection.
鈥?/div>
Lamp driver
鈥?/div>
Programmable logic controller
Dg
H
L
H
H
L
L
L
L
Shorted Output
L
Over-Temperature H
Over-Temperature L
L
L
L
Block Diagram
Vcc
Available Packages
5 Lead SMD220
5 Lead TO-220
GND
OUT
www.irf.com
1
