Data Sheet 60050-H

(NOTE: For new designs, we

recommend IR鈥檚 new products IPS521 and IPS521S)

IR6224

INTELLIGENT HIGH SIDE MOSFET POWER SWITCH

Features

鈥?/div>

PWM current limit for short circuit protection

Over-temperature protection

Active output negative clamp

Reverse battery protection for logic circuit

Broken ground protection

Short to Vcc protection

Low noise charge pump

Sleep mode supply current

4kV ESD protection on all leads

Logic ground isolated from power ground

Product summary

V

cc(op)

5-50V

R

DS

(on)

I

lim

T

j(sd)

E

av

Applications

Truth Table

Condition

Normal

Output Open

Shorted Output

100m

鈩?/div>

20A

170擄C

200mJ

General Description

The IR6224 is a 5 terminal monolithic HIGH SIDE SWITCH with

built in short circuit, over- temperature, ESD protections, induc-

tive load turn off capability and diagnostic feedback.

The on-chip protection circuit goes into PWM mode, limiting the

average current during short circuit if the drain current exceeds

20A. The protection circuit latches off the high side switch if the

junction temperature exceeds 170

o

C and latches on after the

junction temperature falls by 10

o

C. The Vcc (drain) to out

(source) voltage is actively clamped at 55V, improving its perfor-

mance during turn off with inductive loads.

The on-chip charge pump high side driver stage is floating and

referenced to the source of the Power MOSFET. Thus the logic

to power ground isolation can be as high as 50V. This allows

operation with larger offset as well as controlling the switch

during load energy recirculation or regeneration.

A diagnostic pin is provided for status feedback of short

circuit, over temperature and open load detection.

鈥?/div>

Solenoid driver

鈥?/div>

Programmable logic controller

In

H

L

H

L

H

Dg

H

L

H

Current-Limiting

L

PWM Mode

Out

H

L

H

L

Shorted Output

Over-Temperature

H

Over-Temperature

L

Block Diagram

Vcc

Available Packages

5 Lead SMD220

5 Lead TO-220

GND

OUT

www.irf.com

1

標準包裝
50
類別
集成電路 (IC)
家庭
PMIC - MOSFET，電橋驅動器 - 內部開關
系列
-
類型
高端
輸入類型
非反相
輸出數
1
導通狀態電阻
80 毫歐
電流 - 輸出 / 通道
-
電流 - 峰值輸出
20A
電源電壓
5 V ~ 50 V
工作溫度
-40°C ~ 150°C
安裝類型
表面貼裝
封裝/外殼
TO-263-5，D²Pak（4 引線+接片），TO-263BB
供應商設備封裝
D2Pak（SMD-220 5 引線）
包裝
管件
其它名稱
*IR6224S
