IR3093
DATA SHEET
3 PHASE OPTERON, ATHLON, OR VR10.X CONTROL IC
DESCRIPTION
The IR3093 Control IC provides a full featured, cost effective, single chip solution to implement robust
power conversion solutions for three different microprocessor families; 1) AMD鈥檚 Opteron, 2) AMD鈥檚
Athlon or 3) Intel鈥檚 VR-10.X family of processors. The user can select the appropriate VID range with a
single pin. Control and 3 phase Gate Drive functions are integrated into a single cost effective IC. . In
addition to CPU power, the IR3093 offers a compact, efficient solution for high current POL converters.
FEATURES
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
x
5 bit or 6 bit VID with 0.5% overall system accuracy
Selectable VID Code for AMD Opteron or Athlon or Intel VR10.X
Programmable Slew Rate response to 鈥淥n-the-Fly鈥?VID Code Changes
3A GATELX Pull Down Drive Capability
Programmable 100KHz to 540KHz oscillator
Programmable Voltage Positioning (can be disabled)
Programmable Softstart
Programmable Hiccup Over-Current Protection with Delay to prevent false triggering
Simplified Powergood provides indication of proper operation and avoids false triggering
Operates up to 21V input with 7.9V Under-Voltage Lockout
5V UVL with 4.36V Under-Voltage Lockout threshold
Adjustable Voltage, 150mA Bias Regulator provides MOSFET Drive Voltage
Enable Input
OVP Flag Output detects high side fet short at powerup
Pin compatible with IR3092, 2-phase PWM Control IC
Available 48L MLPQ package
ORDERING INFORMATION
Device
IR3093MTR
*
Samples Only
*IR3093M
Order Quantity
3000 per Reel
100 piece strips
PACKAGE INFORMATION
VID2
VID1
VID0
VID5
5VREF
OVPSNS
ENABLE
OVP
CSINP1
CSINM1
NC
VCCH1
Page 1 of 39
LGND
SETBIAS
VCC
CSINP3
CSINM3
BIASOUT
PWRGD
CSINP2
CSINM2
VID_SEL
VCCL3
GATEL3
VID3
VID4
ROSC
VOSNS-
OCSET
VDAC
VDRP
FB
EAOUT
SS/DEL
SCOMP2
SCOMP3
IR3093
48LD MLPQ
GATEH1
PGND1
GATEL1
VCCL1_2
5VUVL
GATEL2
PGND2
GATEH2
VCCH2
VCCH3
GATEH3
PGND3
48L MLPQ
(7 x 7 mm Body)
鈥?/div>
JA
= 27
o
C/W
07/15/04
