IR2151S Datasheet

  • IR2151S

  • Half Bridge Driver. LO In Phase with RT. Programmable Oscill...

  • 6頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Preliminary Data Sheet No. PD60034-J
IR2151
Features
鈥?/div>
Floating channel designed for bootstrap operation
Fully operational to +600V
Tolerant to negative transient voltage
dV/dt immune
Undervoltage lockout
Programmable oscillator frequency
(NOTE: For new designs, we
recommend IR鈥檚 new products IR2153 and IR21531)
SELF-OSCILLATING HALF-BRIDGE DRIVER
Product Summary
V
OFFSET
Duty Cycle
I
O
+/-
V
OUT
Deadtime (typ.)
600V max.
50%
100 mA / 210 mA
10 - 20V
1.2 碌s
鈥?/div>
鈥?/div>
f
=
鈥?/div>
Matched propagation delay for both channels
鈥?/div>
Low side output in phase with R
T
1
1.4
脳
(R
T
+
75
鈩?/div>
)
脳
C
T
Description
The IR2151 is a high voltage, high speed, self-os-
cillating power MOSFET and IGBT driver with both
high and low side referenced output channels. Pro-
prietary HVIC and latch immune CMOS technologies
enable ruggedized monolithic construction. The front
end features a programmable oscillator which is simi-
lar to the 555 timer. The output drivers feature a high
pulse current buffer stage and an internal deadtime
designed for minimum driver cross-conduction. Propa-
gation delays for the two channels are matched to sim-
plify use in 50% duty cycle applications. The floating
channel can be used to drive an N-channel power
MOSFET or IGBT in the high side configuration that
operates off a high voltage rail up to 600 volts.
Packages
8 Lead PDIP
8 Lead SOIC
Typical Connection
up to 600V
V
CC
R
T
C
T
COM
V
B
HO
V
S
LO
TO
LOAD
(Refer to Lead Assignment diagram for correct pin configuration)
1

IR2151S 產品屬性

  • 95

  • 集成電路 (IC)

  • PMIC - MOSFET，電橋驅動器 - 外部開關

  • -

  • 半橋

  • 自振蕩

  • -

  • 125mA

  • 1

  • 2

  • 600V

  • 10 V ~ 20 V

  • -40°C ~ 125°C

  • 表面貼裝

  • 8-SOIC（0.154"，3.90mm 寬）

  • 8-SOICN

  • 管件

  • *IR2151S
