IPS032G Datasheet

  • IPS032G

  • SINGLE/DUAL FULLY PROTECTED POWER MOSFET SWITCH

  • 11頁

  • IRF

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Data Sheet No.PD 60151-J
IPS031G/IPS032G
SINGLE/DUAL FULLY PROTECTED POWER MOSFET SWITCH
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Over temperature shutdown
Over current shutdown
Active clamp
Low current & logic level input
E.S.D protection
Product Summary
R
ds(on)
V
clamp
Ishutdown
70m
鈩?/div>
(max)
50V
12A
1.5碌s
Description
The IPS031G/IPS032G are fully protected single/dual
low side SMART POWER MOSFETs that feature over-
current, over-temperature, ESD protection and drain
to source active clamp.These devices combine a
HEXFET 廬 POWER MOSFET and a gate driver. They
offer full protection and high reliability required in
harsh environments. The driver allows short switch-
ing times and provides efficient protection by turning
off the power MOSFET when the temperature ex-
ceeds 165
o
C or when the drain current reaches 12A.
The device restarts once the input is cycled. The
avalanche capability is significantly enhanced by the
active clamp and covers most inductive load demag-
netizations.
T
on
/T
off
Packages
8-Lead SOIC
IPS031G
Typical Connection
16-Lead SOIC
IPS032G
(Dual)
Load
R in series
(if needed)
D
IN
control
S
Q
S
Logic signal
(Refer to lead assignment for correct pin assignment)
www.irf.com
1

IPS032G 產品屬性

  • 45

  • 集成電路 (IC)

  • PMIC - MOSFET，電橋驅動器 - 內部開關

  • -

  • 低端

  • 非反相

  • 2

  • 45 毫歐

  • 1.65A

  • 15A

  • 4 V ~ 6 V

  • -40°C ~ 150°C

  • 表面貼裝

  • 16-SOIC（0.154"，3.90mm 寬）

  • 16-SOIC N

  • 管件

  • *IPS032G
