AudioCoded Enabling Technology Products
TM
IPM-260
4 E1/T1
PCI VoIP Media Processing Board
The
IPM-260
is a complete VoIP media processing solution providing IP and
PSTN interfaces to build next generation applications for both today聮s and
tomorrow聮s networks. By combining these capabilities on a single board, the
IPM-260 can eliminate a number of separate special-function boards, reducing
inventory, increasing over-all system density, reduce cost and improve time-
to-market.
Deliver Feature-Rich Solution
A broad selection of firmware based media processing capabilities is available
with the IPM-260 including: message record/playback, conferencing, voice
coding, echo cancellation, fax processing and call progress tones detection.
Each channel resource on the IPM-260 is universal and can perform media
processing functions while utilizing full flexibility in endpoints.
Protect Customer Investment
7
IP-enabled, cost-effective technology
7
Field-proven PSTN interface board
7
7
7
7
Low to high channel density
Independent call-by-call basis LBR ports
All-in-one integrated board
Shorter development cycle
The IPM-260 is a member of AudioCodes聮 4
th
generation of the widely deployed
TrunkPack Media Gateway on a blade family. Like the other members of the
TrunkPack family the IPM-260 supports AudioCodes API, which enables
software download, provisioning and control. Maintaining essential API
backward compatibility of future releases in order to protect customers'
investment, is an important feature of AudioCodes' software update/upgrade
program.
Enable Fast & Easy Integration
Enabling accelerated design cycles with high density and reduced costs, the
IPM-260 is an ideal building block for scalable, reliable VoIP enabled media
processing solutions. With the IPM-260聮s comprehensive feature set, customers
can quickly design a wide range of solutions combining PSTN and VoIP
networks.
IPM-260 Features
7
120 universal ports supporting voice, fax and data
7
Various voice compression includes G.711, G.723.1, G.729A
7
Voice Record/Playback
7
Fax termination/generation (T.37)
7
Real-time, multi-party conferencing
7
Interchangeable RTP or PSTN or TDM endpoints
7
Comprehensive IVR control
7
VoIP packet streaming (RTP/RTCP) per RFC 1889/1890
7
MGCP, MEGACO and AudioCodes' proprietary TPNCP
7
MVIP, SCbus and H.100 CT bus interface support
7
Automatic Speech Recognition (ASR)
1
7
Text To Speech (TTS)
1
1
2
