IP113M
Managed 10/100Base-TX / FX Media Converter
1. Feature
A 10/100BASE-TX/ 100BASE-FX converter
with a SMI port for management
Built in a 10/100BASE-TX transceiver
Built in a PHY for 100BASE-FX
Built in a 2-port switch
鈥?Pass all packets without address and CRC
check (optional)
鈥?Supports modified cut-through frame
forwarding for low latency
鈥?Supports pure converter mode data
forwarding for extreme low latency
鈥?Supports flow control for full and half duplex
operation
鈥?Bandwidth control
鈥?Forward 1600 bytes packet for
management
鈥?Optional forward fragments
Built in 128Kb RAM for data buffer
Supports 3.3v I/O tolerance SMI (MDC, MDIO)
and MII registers for management
鈥?Configure local and remote IP113M through
local SMI
鈥?Monitor local and remote IP113M through
local SMI
鈥?Configure/ monitor TP port support
(auto-negotiation or force 10M/100M,
full/half)
鈥?Configure/ monitor flow control, bandwidth
鈥?Supports loop back test (In-band or
out-band, auto or program)
鈥?The maintenance frame is compatible to
TS-1000 standard (the Telecommunication
Technology Committee, TTC)
Supports Statistic Counters
Supports auto MDI-MDIX function
Supports link fault pass through function
Supports far end fault function
LED display for link/activity, full/half, 10/100
Built in a watchdog timer to monitor internal
switch error
Supports EEPROM Configuration
0.25-um CMOS technology
Single 2.5v power supply48-pin LQFP
package
2. General Description
IP113M can be a 10/100BASE-TX to 100BASE-FX
converter or a 100BASE-FX to 100BASE-FX repeater
with an SMI port for management. It consists of a
2-port switch controller, a fast Ethernet transceiver
and a PHY for 100BASE-FX. The transceivers in
IP113M are designed in DSP approach with advance
0.25um technology; this results in high noise immunity
and robust performance.
Besides store and forward mode, IP113M supports
modified cut through mode and pure converter mode
for low latency data forwarding. IP113M can forward
packets up to 1600 bytes to meet requirement of extra
long packets.
IP113M supports remote management function.
Besides remote monitor and loop back test function
defined in TS-1000, IP113M supports remote access
functions. Local IP113M can access the MII register of
remote IP113M by programming local IP113M鈥檚 MII
registers via SMI. IP113M implements the
management function using the maintenance frame
defined in TS-1000.
IP113M supports IEEE802.3x, collision base
backpressure, and various LED functions, etc.
These functions can be configured to fit the different
requirements by feeding operation parameters via
EEPROM interface or pull up/down resistors on
specified pins.
1/48
Copyright 漏 2003, IC Plus Corp.
All rights reserved.
preliminary, Specification subject to change without notice.
IP113M-DS-R02
May. 19, 2003
