INT2095

Intronic Semiconductor, Inc. U

Interface Transceiver

INT2095

Features

鈥?/div>

Pin-for-Pin replacement for industry-standard

PEB2095 part

Up to 2.0km line interface performance

NT (LT) and TE mode support

IOM1 and IOM2 backplane interface modes

Special function pins for interface to other

INT2095鈥檚 or layer-2 devices

Custom versions with Intronic core technology

Low Power dynamic operation

Single 5V supply

28-pin PLCC (standard) package

Description

The Intronic Semiconductor INT2095 is a fully

featured replacement for the industry standard

Up interface layer-1 device. It supports loop

lengths up to 2.0km over AWG24 cable and

provides all signal conditioning, equalization and

adaptive threshold adjustment to optimize line

performance. The backplane interface supports

both IOM1 and IOM2 modes and provides

access to all subchannels of the interface

including B, D, CI and M-channels. Special

function pins (X0-X4) and a master clock output

are included in the device for integration with

other INT2095鈥檚 or layer-2 devices.

鈥?/div>

INT2095V5

March, 2001
