IL91531
PARALLEL INPUT TONE/PULSE DIALER
H
IGH
-P
ERFORMANCE
S
ILICON
-G
ATE
CMOS
The IN91531N provides a 4-bit data input and a handshaking signal to serve as
microcomputer interfaces. Under microcomputer control the IN91531N generates both a
DTMF signal and a pulse output for telephone dialing.
All necessary dual-tone frequencies and dial pulse
outputs are derived from the widely used TV crystal
standard, providing high accuracy and stability. The
required sinusoidal waveform for individual tones is
digitally synthesized on the chip, resulting in a
waveform with very low total harmonic distortion.
鈥?/div>
4-bit parallel data input from microcomputer
鈥?/div>
TTL compatible inputs and outputs
鈥?/div>
Uses TV crystal standard (3.58 MHz) to derive all
ORDERING INFORMATION
frequencies, providing high accuracy and stability
IN91531N
T
A
= -10擄 to 70擄 C
鈥?/div>
Operating voltage: 2.5 to 5.5 Volts
鈥?/div>
Selectable M/B ratio
鈥?/div>
10 PPS dial rate
鈥?/div>
DTMF signaling of digits 0 9, *, #, A, B, C, and D
鈥?/div>
Pulse signaling of 0
鈭?/div>
9, *, #, and A
鈥?/div>
High group tone pre-emphasis: 2 dB
鈥?/div>
Low total harmonic distortion in DTMF
PIN ASSIGNMENT
signaling
VCC
0.1mk
01
MODE
03
M/B
04
T/P
05
06
D1
07
D2
08
D3
13
CE
02
LATCH
16
VCC
DP
14
ACK
15
TONE
09
2.5 - 10k
TTL - compatible
D0
2.2k
12
OSCI
3.58MHz
11
OSCO
GND
10
Korzhenevskogo 12, Minsk, 220064, Republic of
Belarus
Fax: +375 (17) 278 28 22,
Phone: +375 (17) 278 07 11, 277 24 70, 277 24 61,
277 69 16
E-mail: belms@belms.belpak.minsk.by
URL: www.bms.by
