IL9002N
OPERATIONAL AMPLIFIE R
The IL9002N is a very high precision op amp with an offset voltage maximum of
250碌V. Offering also low input current (14nA) and high gain (120V/mV), the IL07N is
particularly suitable
for instrumentation applications.
FEATURES:
EXTREMELY LOW OFFSET : 250碌V MAX
LOW INPUT BIAS CURRENT : 14nA
LOW Vio DRIFT : 0.5mV/
o
C
SUPPLY VOLTAGE RANGE :鹵 13V to 鹵 18V
Symbol
Vcc
V,d
Vi
Toper
Parameter
Supply Voltage
Differential Input Voltage
Input Voltage
Operating Temperature
Value
鹵15
鹵5
鹵10
-10 to +70
Unit
V
V
V
擄c
ELECTRICAL CHARACTERISTICS
Vcc = 鹵15V, Tamb = +25擄C (unless otherwise specified)
Symbol
Vo
Vio
Icc
Avd
CMR
Vicm
SVR
SR
Dvio
Dlio
Parameter
MaxOutput Voltage
Input Offset Voltage
Supply Current
Large Signal Voltage Gain
Common Mode Rejection
Ratio
Max Input Common Mode
Voltage Range
Supply Voltage Rejection
Ratio
Slew Rate
Input Offset Voltage Drift
Input Offset Current Drift
Mode
Ucc=15V
Ucc=16,5V
Ucc=15V
Ucc=16,5V
Ucc=15V
Ucc=16,5V
Ucc=15V
Ucc=16,5V
Min.
鹵11.5
鹵10
Typ.
Max.
Unit
V
碌V
mA
V/mV
dB
鹵15
-
-
V
dB
V/碌S
6.0
200
碌v/擄C
nA/擄C
150
250
鹵12
鹵14
120
120
94
鹵13
90
0.1
