2.3 mm High SMD package
High sensitivity (K1) at low operating LED current
Couples AC and DC signals
Low input-output capacitance
Isolation test voltage, 2500 V
RMS
, 1 second
Low distortion, below -80 db
0.4 mm internal insulation thickness
i179085
K 1
A 2
B1 3
C1 4
K1
K2
8 C2
7 B2
6 N.C
5 N.C
Applications
Optical DAA for V.34 FAX/Modem PCMCIA cards
Digital telephone line isolation
Description
The IL388 family of linear optocoupler consist of an
IRLED optically coupled to two photodiodes. The
emitter is located such that both photodiodes receive
approximately an equal amount of infrared light. The
diodes produce a proportional amount of photocur-
rents. The ratio of the photocurrents stays constant
with high accuracy when either the LED current
changes or the ambient temperature changes. Thus
one can control the output photodiode current.
The IL388 optocouplers can be used with the aid of
operational amplifiers in closed loop conditions to
achieve highly linearly and electrically AC and or DC
signals amplifiers.
Order Information
Part
IL388
Remarks
Couples AC and DC signals, SMD-8
For additional information on the available options refer to
Option Information.
Absolute Maximum Ratings
T
amb
= 25 擄C, unless otherwise specified
Stresses in excess of the absolute Maximum Ratings can cause permanent damage to the device. Functional operation of the device is
not implied at these or any other conditions in excess of those given in the operational sections of this document. Exposure to absolute
Maximum Rating for extended periods of the time can adversely affect reliability.
Input
Parameter
Reverse voltage
Forward current
Surge current pulse width < 10
碌s
Power dissipation
Derate linearly from 25 擄C
Junction temperature
T
j
Test condition
Symbol
V
R
I
F
I
PK
P
diss
Value
鈮?/div>
3.0
鈮?/div>
30
鈮?/div>
150
鈮?/div>
150
鈮?/div>
2.0
鈮?/div>
100
Unit
V
mA
mA
mW
mW/擄C
擄C
Document Number 83625
Rev. 1.3, 26-Apr-04
www.vishay.com
1
IL388 產品屬性
Vishay
高線性光耦合器
詳細信息
AC/DC
2.1 V
3 V
30 mA
250 mW
+ 75 C
0 C
SOP-8
Tube
30 mA
2130 Vrms
Photodiode
DC
720
