IL352 Datasheet

  • IL352

  • Optocoupler, Phototransistor Output, With Base Connection

  • 7頁

  • VISHAY   VISHAY

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IL352
Vishay Semiconductors
Optocoupler, Phototransistor Output, With Base Connection
Features
鈥?Good CTR Linearly Depending on
Forward Current
鈥?Isolation Test Voltage, 3000 V
RMS
鈥?High Collector-Emitter Voltage, V
CEO
= 30 V
鈥?Low Saturation Voltage
鈥?Fast Switching Times
鈥?Lead-free component
鈥?Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
N.C
1
A
2
C
3
N.C
4
8
B
7
C
6
5
E
i179027
e3
Pb
Pb-free
Agency Approvals
鈥?UL1577, File No. E52744 System Code S
鈥?DIN EN 60747-5-2 (VDE0884)
DIN EN 60747-5-5 pending
Available with Option 1
The coupling device is designed for signal transmis-
sion between two electrically separated circuits. The
potential difference between the circuits to be coupled
must not exceed the maximum permissible reference
voltages.
Description
The IL352 optically coupled isolator that features a
high current transfer ratio, low coupling capacitance
and high isolation voltage. It has a GaAs infrared
emitting diode emitter, which is optically coupled to a
silicon planar phototransistor detector. The compo-
nent is housed in a thin line package.
Order Information
Part
IL352
Remarks
CTR > 100 %, SMD-8
For additional information on the available options refer to
Option Information.
Absolute Maximum Ratings
T
amb
= 25 擄C, unless otherwise specified
Stresses in excess of the absolute Maximum Ratings can cause permanent damage to the device. Functional operation of the device is
not implied at these or any other conditions in excess of those given in the operational sections of this document. Exposure to absolute
Maximum Rating for extended periods of the time can adversely affect reliability.
Input
Parameter
Reverse voltage
DC forward current
Total power dissipation
Derate linearly from 25 擄C
Test condition
Symbol
V
R
I
F
P
diss
Value
6.0
60
50
0.66
Unit
V
mA
mW
mW/擄C
Document Number 83624
Rev. 1.5, 26-Oct-04
www.vishay.com
1

IL352 產品屬性

  • Vishay

  • 晶體管輸出光電耦合器

  • 1 Channel

  • DC

  • 70 V

  • 0.3 V

  • 3000 Vrms

  • 1.5 V

  • 100 mA

  • 50 mW

  • + 85 C

  • - 40 C

  • SOP-7

  • Reel

  • 60 mA

  • 6 V

  • Phototransistor

  • DC

  • 720
